RGB LED Strobe Bar Light
Crisp PULSARIS BAR 720B is a dynamic indoor LED bar designed to deliver high-impact lighting effects for stages, clubs, theaters, and architectural installations. With a blend of RGB and white LEDs, built-in macro effects, and full DMX control, it’s ideal for creating both subtle ambiance and energetic strobe scenes.
Crisp PULSARIS BAR 720B Competitive Differences
- 314 built-in macro effects across RGB, RGBW, and white LED combinations
- 48 RGB and 24 white LED sections for zoned pixel control and striking visuals
Crisp PULSARIS BAR 720B Description
The
PULSARIS BAR 720B combines artistic control with raw power in a compact, versatile fixture. With 480 RGB LEDs and 240 white LEDs split into 48 RGB and 24 white control zones, this bar is capable of complex chase patterns, pixel mapping, and smooth color fades.
Perfect for live events, concerts, clubs, and immersive installations, it offers 314 built-in macro effects — including 126 RGB, 126 RGBW, and 62 white presets — enabling quick, professional-level visuals without the need for programming.
The unit supports 4, 16, and 168-channel DMX modes for everything from simple plug-and-play control to advanced pixel mapping setups. Wash and strobe effects come with adjustable speed and a 0–100% linear dimmer, while the wide 120° beam angle ensures strong coverage across stages and walls.
Reliable and efficient, the
PULSARIS BAR 720B offers 50,000-hour LED lifespan, IEC power I/O, and 3-pin XLR DMX connectivity. Housed in a sleek black chassis, it’s built for professional use in controlled indoor environments.
Model Features
- 48 RGB sections + 24 white LED sections for dynamic zoned control
- 314 built-in macro effects (RGB, RGBW, white)
- Wash and strobe modes with adjustable speed
- Supports 4, 16, or 168 DMX channels for flexible control
- Auto, Sound, DMX, and Master/Slave operation modes
- 0–100% linear dimming and 1–30Hz strobe rate
- Integrated DMX and IEC cables for streamlined setup
Model Specifications
- Power Supply: AC100–240V, 50/60Hz
- Power Consumption: 250W
- LED Source: 480pcs RGB SMD 5050, 240pcs 0.5W white 5730 LEDs
- Color System: RGB + White
- Beam Angle: 120°
- DMX Channels: 4 / 16 / 168 CH
- Control Modes: DMX, Auto, Sound Active, Master-Slave
- Connectors: 3-pin DMX I/O (integrated), IEC power I/O (integrated)
- IP Rating: IP20 (indoor use)
- Operating Temp: -10°C to 40°C (14°F to 104°F)
- Dimensions: 38.6 x 3.4 x 4.6 in (980 x 85 x 116 mm)
- Weight: 10 lb (4.5 kg)
What's In The Box
- PULSARIS BAR 720B fixture
- Power cable (IEC, attached)
- Quick start guide
Crisp PULSARIS BAR 720B
(Event Lighting SPL-LED-720B)
