RCF NXL 44-A MK2 – High-Power Column Line Array Reinvented
The
RCF NXL 44-A MK2 is a cutting-edge active column array speaker designed for serious touring applications, DJs, live bands, clubs, and event rental setups. Combining
three 10” neodymium woofers, a
3” titanium compression driver, and a powerful
2100W Class-D amplifier, the NXL 44-A MK2 delivers astonishing clarity, depth, and power — reaching up to
135 dB SPL with focused 100° x 25° coverage.
Engineered from the ground up for superior sonic precision, it features
FiRPHASE linear phase processing and
Bass Motion Control (BMC) for distortion-free full-range performance all the way down to
45 Hz. Whether used as a stand-alone column, flown in arrays, or pole-mounted with a subwoofer, this speaker system offers flexibility and road-ready durability.
Key Features
- 135 dB Max SPL for high-output applications
- 2100W peak Class-D amplifier with convection cooling (fanless)
- 3 x 10” high-power neodymium woofers with 2.5” voice coils
- 1.4” exit / 3” voice coil titanium HF compression driver
- 100° x 25° constant directivity dispersion
- 45 Hz – 20,000 Hz linear frequency response
- FiRPHASE DSP for perfect timing and image
- Bass Motion Control for woofer excursion management
Advanced Line Array Design
Unlike traditional point source or standard column speakers, the NXL 44-A MK2 offers true line-array behavior in a single enclosure. Its vertical waveguide minimizes reflections and enhances intelligibility, especially in acoustically challenging spaces. For extended coverage and throw,
two NXL 44-A MK2 speakers can be cascaded vertically without compromising phase or dispersion.
RCF Engineering – Performance You Can Trust
- FiRPHASE Technology: Delivers phase-coherent sound across the listening area with near-zero latency.
- BMC (Bass Motion Control): Replaces traditional high-pass filtering with a smart algorithm that limits only damaging excursions, allowing for full-range clarity and deep bass without phase issues.
- All-in-One Amplification: The fanless 2-channel Class-D amp (1400W LF + 700W HF) is energy-efficient, lightweight, and fully protected.
Ready for the Road or Install
The
Baltic birch plywood cabinet is finished in a durable black coating and protected by a heavy-duty steel grille. With
8x M8 rigging points and
8x quick-lock slots, the NXL 44-A MK2 is ready for pole mounting, flying, truss setups, or installed use in clubs or venues.
Perfect For:
- Mid-sized live concerts and band performances
- High-output DJ systems
- Permanent club or event space installations
- Touring rigs and portable PA setups
Technical Specifications:
- Max SPL: 135 dB
- Frequency Response: 45 Hz – 20,000 Hz
- Coverage: 100° H x 25° V
- Transducers:
- 1 x 1.4” exit, 3” v.c. titanium compression driver
- 3 x 10” neodymium woofers, 2.5” v.c.
- DSP Controls: Linear, 2 Speakers (coupled), High-Pass Presets, Volume
- Input/Output: Combo XLR/Jack input, XLR output
- Power: 2100W Peak (1400W LF + 700W HF)
- Power Connectors: PowerCON TRUE1 TOP In/Out
Build & Dimensions:
- Cabinet: Baltic Birch Plywood
- Grille: Powder-coated steel
- Mounting Options: 8 x M8 rigging points, 8 x quick-lock points, 35 mm pole mount
- Handles: 2 side ergonomic handles
- Dimensions (HxWxD): 1080 x 297.5 x 373 mm / 42.52 x 11.71 x 14.69 in
- Weight: 33.4 kg / 73.63 lbs
What’s in the Box:
- RCF NXL 44-A MK2 Speaker
- PowerCON TRUE1 TOP Power Cable
- User Manual
For the discerning audio professional, the NXL 44-A MK2 is the ultimate blend of output, clarity, and versatility in a rugged yet elegant column format. Whether for portable gigs or fixed installations, it raises the bar in performance, power, and sound integrity.
