Allen and Heath AHM-64

Advanced Audio Matrix Processor for Professional Sound Management

The Allen & Heath AHM-64 is a cutting-edge audio matrix processor designed for sound management in a variety of professional environments, including corporate settings, hospitality venues, educational institutions, event spaces, and more. Whether you're managing audio distribution, paging, conferencing, or speaker processing, the AHM-64 offers unparalleled flexibility and control, making it an ideal choice for complex audio installations in multipurpose venues like college campuses, theaters, cruise ships, and sports arenas.

The AHM-64 is part of an expanded ecosystem that includes remote audio expanders, remote controllers, interfaces, apps, and software. This ecosystem supports a wide range of configurations, including portable, rackmountable, and wallmountable setups, with options for proprietary point-to-point Layer-2 or Dante transport protocols. Additionally, the AHM-64 is compatible with IP remote controllers for volume control, music source selection, preset recall, and more, and it integrates seamlessly with third-party devices over GPIO, TCP/IP, and various control systems like Crestron, AMX, and Extron.

Allen & Heath AHM-64 Competitive Differences

• 64x64 processing matrix with 12x12 local analog I/O for versatile audio routing.
• 96 kHz FPGA core ensures ultralow latency and superior sound quality.
• I/O port supports up to 128x128 audio networking, with a Dante 96 kHz option card available.
• 64 configurable processing outputs for mono/stereo zones or speaker processing.
• Compatible with Allen & Heath IP1, IP6, and IP8 remote controllers for flexible control options.
• Includes powerful sound management tools like AEC, ANC, priority ducking, and 8-band PEQ.
• Supports integration with third-party devices via TCP/IP and GPIO, with drivers for Crestron, AMX, and Extron.
• Mac/Windows System Manager software and Custom Control app for easy setup and operation.

Allen & Heath AHM-64 Features

• 64x64 audio matrix with 12x12 local I/O (12x Block 3-Pin Line/Mic Inputs, 12x Block 3-Pin Line Outputs)
• I/O Port for audio networking up to 128x128 channels, with Dante 96 kHz option card (AES67 and DDM ready)
• 64 configurable processing outputs for mono/stereo zones or speaker processing
• 96 kHz FPGA core with ultralow latency for high-quality audio performance
• Sound management tools: Automatic Mic Mixer, Acoustic Echo Cancellation (optional), Ambient Noise Compensation, Priority Ducking
• 8-band PEQ, dynamics, and delay on every input and zone, plus speaker processing with crossover filter, delay, limiter, and PEQ
• Compatible with Allen & Heath IP remote controllers (IP1, IP6, IP8)
• 2x2 local GPIO plus networkable GPIO interface for external device control
• TCP/IP protocol for integration with third-party devices, with Crestron, AMX, and Extron drivers available
• DC backup power supply for reliable operation in critical environments
• Mac/Windows System Manager software and Custom Control app for user-friendly setup and control
• Integrated stereo playback and event scheduler for automated operations
• 32 user profiles for customized access and control

Allen & Heath AHM-64 Specifications

• Compatibility: Not Specified by Manufacturer
• Audio I/O: 12x Block 3-Pin Line/Mic Inputs, 12x Block 3-Pin Line Outputs
• Power Source: AC Input (Included)
• AC Input Power: 100 to 240 VAC, 50 / 60 Hz
• DC Input Power: 12 VDC at 8 A
• Power Consumption: 70 W (Maximum)
• Operating Temperature: 32 to 72°F / 0 to 40°C
• Color: Black
• Dimensions: 19 x 14.3 x 3.6" (48.3 x 36.3 x 9.1 cm)
• Weight: 15.5 lb (7 kg)

Packaging Information

• Package Weight: 19.8 lb
• Box Dimensions (LxWxH): 23.4 x 20.1 x 8.4"

Allen & Heath AHM64 (Allen & Heath AH-AHM-64)
