Fixed Indoor LED Video Panel
The
BrightBox Osiris 3.9 is a high-performance indoor LED video panel designed for fixed installations that demand clarity, brightness, and reliability. With a fine 3.9mm pixel pitch and 900-nit brightness, it delivers sharp, vibrant visuals ideal for retail displays, corporate environments, houses of worship, and entertainment venues. Its lightweight build and ultra-slim profile make for fast, clean wall or hang-mounted installations.
BrightBox Osiris 3.9 Competitive Differences
- High-refresh-rate (≥3,840Hz) SMD2020 LED technology
- Front-serviceable, ultra-slim panel for seamless wall installs
BrightBox Osiris 3.9 Description
The
BrightBox Osiris 3.9 stands out with a 3.9mm pixel pitch and 128x128 panel resolution, optimized for clear indoor content at close viewing distances. Its direct-mountable and hang-mountable design offers flexibility for both permanent and semi-permanent installations, while the all-black SMD2020 LEDs ensure high contrast and excellent image clarity.
This panel achieves a refresh rate of ≥3,840 Hz for smooth, flicker-free playback — perfect for digital signage, advertising, or dynamic visual environments. It’s built for long-term performance, featuring a 100,000-hour lifespan and efficient front service access that minimizes downtime during maintenance.
Certified for safety and reliability (ETL, FCC, CE, ROHS), and backed by a 3-year warranty, the Osiris 3.9 is a robust solution for indoor LED video wall systems. Whether used as a single panel or part of a larger display, it delivers a professional-grade visual experience.
Model Features
- 3.9mm pixel pitch for crisp image detail
- 900 nit brightness for visibility in ambient light
- Front-serviceable for easy maintenance
- Slim 2.4-inch depth for direct wall mounting
- ≥3,840 Hz refresh rate for smooth video playback
- ETL, FCC, ROHS, and CE certified
Model Specifications
- Pixel Pitch: 3.9 mm
- LED Type: Black SMD2020
- Pixel Resolution: 128 x 128
- Panel Dimensions: 19.6″ x 19.6″ x 2.4″ (500 x 500 x 63 mm)
- Weight: 15.2 lb (6.9 kg)
- Brightness: 900 Nit
- Refresh Rate: ≥3,840 Hz
- Grayscale: 16-bit
- Scan Mode: 1/16
- Pixel Density: 65,536 dots/m²
- Power Consumption (Max): 200W
- Input Power: 600W
- IP Rating: IP30 (Front), IP20 (Rear)
- Serviceability: Front
- Control System: Novastar
- Lifespan: 100,000 hours
- Certifications: CE, RoHS, FCC, ETL
- Warranty: 3 Years
- UPC: 618528598505
Jmaz BB1003
(BrightBox Osiris 3.9 Fixed)
