Portable Lighting Console for Touring & Theatre
ChamSys MagicQ MQ70 is a compact, tour-ready lighting console that delivers professional-grade control in a carry-on-sized chassis. Supporting 24 universes (expandable to 48) and featuring a fanless, silent design, it’s perfect for broadcast, corporate, and theatrical environments where space, portability, and quiet operation are essential.
ChamSys MagicQ MQ70 Competitive Differences
- 24 universes direct from console, expandable to 48 with no external nodes
- Built-in UPS for power failure protection—keeps console and network alive
ChamSys MagicQ MQ70 Description
The
MagicQ MQ70 is part of ChamSys’ next-gen compact range, combining powerful features with portability. At just 7kg and under 21 inches wide, it fits in carry-on luggage for most major airlines, making it ideal for fly dates and international productions.
This console includes 4 assignable DMX outputs with RDM support and 3 network ports for ArtNet, sACN, and Pathport distribution. It runs ChamSys MagicQ software, supporting advanced lighting control, pixel mapping, and visualisation. The 10.1" high-resolution multi-touch display offers quick access to programming and show playback, while illuminated fader tracks and encoders enhance visibility in dark environments.
A standout feature of the MQ70 is its internal UPS, which safeguards against power loss without interrupting Ethernet switches or playback. With built-in Wi-Fi, remote app support is seamless—no router setup required. Silent operation, MIDI I/O, LTC timecode input, and a full suite of external connectivity options make it a versatile choice for complex shows in sensitive settings.
Model Features
- 10.1" HD multi-touch screen with intuitive interface
- 24 universes output, expandable to 48
- Inbuilt UPS for safe power failover
- 4 DMX outputs with RDM support
- 3 network ports for ArtNet, sACN, Pathport
- Built-in Wi-Fi for MagicQ Remote App
- 10 playbacks with dual-color illuminated faders
- 8 rotary encoders with illuminated tracks
- Fanless, silent operation—ideal for theatres and studios
Model Specifications
- Universes Supported: 24 (Expandable to 48)
- Max DMX Channels: 12,288 (Expandable to 24,576)
- Max Fixtures Supported: 12,288 (Expandable to 24,576)
- Max Cues: 5000
- Cue Stacks: 2000
- Groups: 5000
- Palettes: 4096
- Media Server Layers: 50
- DMX Outputs: 4 x 5-pin XLR
- Network Ports: 3
- USB Ports: 5
- Audio Input: 1 (7-band)
- Audio Output: Yes
- MIDI Ports: 1 In, 1 Out
- LTC Timecode Input: 1
- Remote Input: 1
- Power Input: Neutrik powerCON TRUE1 (110–240V AC)
- Power Consumption: Max 35W
- Console Dimensions: 20.6 x 13.7 x 2.3 in (525 x 350 x 60 mm)
- Console Weight: 15.4 lb (7 kg)
- Boxed Dimensions: 26.7 x 11.4 x 19.6 in (680 x 290 x 500 mm)
- Boxed Weight: 22 lb (10 kg)
- Flightcase Dimensions: 23.6 x 7.95 x 16.5 in (600 x 202 x 421 mm)
- Flightcase Weight: 37.4 lb (17 kg)
What's In The Box
- ChamSys MagicQ MQ70 Console
- Dual Colour Desk Light
- Dust Cover
- Neutrik powerCON TRUE1 Power Cable
Chamsys CHAMMQ70
(ChamSys mq70)
