Chauvet DJ Obsession HP

Create eye-popping, animated gobo light shows with Obsession HP, a compact LED effect light fitted with a 100W LED that projects multi-colored, rotating gobos. Obsession HP’s design power and flexibility reaches new heights because gobos are interchangeable and the onboard mirror dish and separate color and gobo wheels easily generate complex lighting looks. Generate a synchronized show in Master/Slave mode with up to 2 units and save time running cables and extension cords by power linking multiple units. Obsession HP is compatible with IRC-6 for flexible control over all features and fits best in the CHS-40 VIP Gear Bag.

Features:
Compact LED effect light fitted with a 100W LED projects multi-colored, rotating gobos

Increase design flexibility and effects with inter-changeable gobos

Easily generate complex looks using the rotating gobo wheel plus mirror dish

Generate a synchronized show in Master/Slave mode with up to 2 units

Separate color and gobo wheels allow for creative programming

Quickly and easily change gobos using the easy-access gobo door
Includes 10 popular holiday gobos

Compatible with IRC-6 for flexible control over all features

Save time running cables and extension cords by power linking multiple units

Fits best in the CHS-40 VIP Gear Bag

Includes 10 popular holiday gobos

Specifications:
DMX Channels: 2 or 8DMX Connectors: 3-pin XLRColors: 6 + white, split colors, continuous scroll at variable speedsGobos: (7 metal), rotating, indexing, interchangeable, continuous scroll at variable speedsLight Source: 1 LED (cool white) 100 W, (4 A), 50,000 hours life expectancyStrobe Rate: 0 to 20 HzPWM Frequency: 4 KHzCoverage Angle: 116°Power Linking: 3 units @ 120 V; 6 units @ 230 VInput Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)Power and Current: 176 W, 2.2 A @ 120 V, 60 Hz
171 W, 1.3 A @ 230 V, 50 HzGobo Size: 18.6 mm outside, 12 mm image, 5 mm max thicknessWeight: 10.2 lb (4.7 kg)Size: 14.96 x 8.26 x 12 in (380 x 233 x 305 mm)Approvals: CEOptional Controller: IRC-6

Obsession HP
10 popular holiday gobos
Power cord
Quick Reference Guide
