High-Output Single Source LED Wash with CMY, Zoom and Beam Effects
The
Chauvet Pro Maverick Force 2 SoloWash is a fully featured, compact 480W LED yoke wash fixture designed to deliver rich color, smooth zoom, and flexible beam control. With its single-source LED engine, rotating gobo wheel, CMY + CTO color system and high CRI filters, this wash light blends traditional stage wash aesthetics with the modern tools lighting designers expect.
Chauvet Pro Maverick Force 2 SoloWash Competitive Differences
- Powerful 480W cold white single-source LED with up to 39,200 lumens (source)
- CMY + CTO color mixing system plus a color wheel with CRI and CTB filters
- High CRI filter raises CRI from 70.4 to 87.7 for true-to-life color rendering
- Expansive 6.3° to 55.7° zoom range with beam, field and cutoff angle control
- Rotating gobo wheel with 7 interchangeable geometric gobos
- 5-facet rotating linear prism and motorized frost for beam shaping
- Multiple selectable PWM refresh rates up to 15,000 Hz for flicker-free camera use
- Supports DMX, sACN, Art-Net, W-DMX and RDM for flexible control integration
- Fail-safe Ethernet passthrough keeps data flowing even without fixture power
- Battery-powered display with auto-rotation and USB software update port
Chauvet Pro Maverick Force 2 SoloWash Description
The
Maverick Force 2 SoloWash is engineered to bring a refined wash effect to modern productions. Its 480W LED engine delivers an intense output of up to 39,200 source lumens (30,967 lumens measured) through a precision lens system that supports a zoom range from 6.3° to 55.7°. With this wide range, designers can dial in both tight beam effects and smooth, wide-area washes.
The fixture offers advanced color control through a CMY + CTO mixing system and an independent color wheel that includes CRI and CTB filters. This makes it ideal for broadcast and camera applications, with the ability to shift the CRI rating up to 87.7. The unit also includes a rotating gobo wheel with seven interchangeable geometric patterns, a linear 5-facet prism, and motorized frost, providing flexible options for beam shaping and mid-air visuals.
Connectivity includes DMX, RDM, sACN, Art-Net and W-DMX wireless, along with a fail-safe Ethernet passthrough and USB type-C port for software updates. The fixture includes three onboard user presets and a battery backup display that rotates based on orientation, streamlining rigging and configuration. Compact, powerful and fully featured, the Maverick Force 2 SoloWash is ideal for stage, concert, broadcast and theatrical lighting environments.
Maverick Force 2 SoloWash Features
- 480W single-source cold white LED engine
- CMY + CTO color mixing with wide palette control
- Independent color wheel with 7 colors, CRI and CTB filters
- High CRI filter increases color rendering accuracy
- Rotating gobo wheel with 7 interchangeable metal gobos
- Motorized zoom range from 6.3° to 55.7°
- Motorized focus, frost and iris
- 5-facet rotating linear prism
- 16-bit dimming and five dimmer curve options
- Electronic shutter and strobe (0 to 20 Hz)
- Pan: 540°, Tilt: 270°, with multiple range options
- Move-in-Black function for clean transitions
- Selectable PWM rates: 600 Hz to 15,000 Hz
- DMX channel modes: 21 or 27 channels
- Control protocols: DMX, Art-Net, sACN, RDM, W-DMX
- Fail-safe Ethernet passthrough
- Three preset modes with sync for fast setup
- Battery-powered display with auto screen rotation
- USB-C port for firmware updates
Maverick Force 2 SoloWash Specifications
- LED Source: 1 x 480W cold white LED (50,000-hour lifespan)
- Color Temperature: 7308K native (range: 7308K to 3007K)
- CRI: 70.4 standard, 87.7 with CRI filter
- Zoom Range: 6.3° to 55.7°
- Beam Angle: 6.3° to 32.8°
- Field Angle: 9.3° to 49.5°
- Cutoff Angle: 11.2° to 55.7°
- Source Lumens: 39,200
- Measured Output: 30,967 lumens
- Illuminance (6.3°): 91,362 lux at 5 meters
- Illuminance (55.7°): 3989 lux at 5 meters
- Select PWM Rates: 600, 1200, 2000, 4000, 6000, 15000 Hz
- Pan: 540° (selectable 180°, 360°, 540°)
- Tilt: 270° (selectable 90°, 180°, 270°)
- DMX Modes: 21-channel and 27-channel
- Power Input: 100 to 240V AC, 50/60 Hz (auto-ranging)
- Power Consumption:
- 660W, 5.57A @ 120V
- 649W, 3.24A @ 208V
- 641W, 3.07A @ 230V
- Housing: Aluminum diecast, flame-retardant polymer and steel
- Color: Black
- IP Rating: IP20 (dry location only)
- Noise Level: 32.8 dB (idle), 44.2 dB (full)
- Operating Temperature: 14°F to 113°F (–10°C to 45°C)
- Dimensions (L x W x H): 16.8 in x 10.7 in x 25.8 in (426 mm x 272 mm x 656 mm)
- Weight: 53.4 lb (24.2 kg)
- Certifications: CE, MET, FCC, UKCA
What’s In The Box
- Chauvet Pro Maverick Force 2 SoloWash fixture
- Seetronic Powercon IP65 power cord
- (2) 140 mm Omega brackets with mounting hardware
Chauvet MAVERICKFORCE2SOLOWASH
(Chauvet Pro Maverick Force 2 Solo Wash)
