Warm White LED Fresnel
The CHAUVET Professional Ovation F-265WW is a high-output LED Fresnel designed to produce a bright, soft-edged warm white field for theatrical, broadcast, studio, and production lighting. Its 230W warm white LED delivers a CRI of 96 and a 3142 K color temperature, while motorized zoom provides flexible beam control for both focused illumination and wide wash coverage.
CHAUVET Professional Ovation F-265WW Competitive Differences
- 230W warm white LED produces output comparable to a traditional 2,000W tungsten Fresnel
- High CRI of 96 provides accurate color rendering for theater, television, and camera applications
- Motorized zoom provides a 16° to 68° zoom range for flexible positioning and coverage
- 16-bit dimming and four selectable dimming modes provide exceptionally smooth fades
- Selectable PWM frequencies up to 25 kHz help minimize flicker in broadcast and camera applications
- Virtually silent operation makes the fixture well suited for noise-sensitive theaters and studios
- DMX and RDM control provide flexible integration into professional lighting systems
- Power input and output connections support power linking for streamlined installations
CHAUVET Professional Ovation F-265WW Description
The CHAUVET Professional Ovation F-265WW combines the familiar soft-edged output of a traditional Fresnel with the efficiency, control, and long service life of LED technology. Its 230W warm white LED is rated for up to 50,000 hours and produces a 3142 K output with a CRI of 96, making it particularly suitable for illuminating performers, scenery, and sets where natural skin tones and accurate color reproduction are important.
A motorized zoom system allows the fixture to adapt quickly to changing production requirements. The beam angle adjusts from 16° to 46°, while the field angle ranges from 27° to 68°. Zoom can be controlled through DMX or directly from the fixture, making it practical for theater, television, houses of worship, studios, and other professional environments.
Electronic 16-bit dimming provides smooth fades, with four selectable dimming modes available to tailor the response to different programming styles. The electronic shutter supports strobe rates from 0 to 30 Hz, while selectable PWM frequencies of 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, and 25,000 Hz allow the fixture to be optimized for camera use.
The Ovation F-265WW is built in a durable aluminum alloy and die-cast housing and supports both 3-pin and 5-pin DMX connections. RDM compatibility enables remote fixture configuration and monitoring, while its quiet operation makes it especially useful in applications where fan noise could interfere with performances, dialogue, or recording.
Ovation F-265WW Features
- High-output warm white LED Fresnel fixture
- 230W warm white LED light source
- Output comparable to a traditional 2,000W tungsten Fresnel
- CRI: 96
- Color Temperature: 3142 K
- Motorized zoom
- 16° to 68° zoom range
- 16-bit electronic dimming
- Four selectable dimming modes
- Electronic shutter and strobe
- 0 to 30 Hz strobe rate
- Selectable PWM up to 25 kHz
- DMX and RDM control
- 3-pin and 5-pin XLR data connections
- OLED full-text display
- Power linking capability
- Virtually silent operation
- 7.5-inch accessory holder and gel frame size
- Designed for theater, television, studio, and production applications
Ovation F-265WW Specifications
- Fixture Type: Warm white LED Fresnel
- Light Source: 1 x 230W warm white LED
- LED Current: 3.6 A
- LED Life Expectancy: 50,000 hours
- Color Temperature: 3142 K
- CRI: 96
- Beam Angle: 16° to 46°
- Field Angle: 27° to 68°
- Zoom Range: 16° to 68°
- Output at 27°: 9,283 lumens
- Output at 68°: 12,802 lumens
- Illuminance at 27°: 4,010 lux at 5 m
- Illuminance at 68°: 1,162 lux at 5 m
- Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
- Dimmer: Electronic
- Dim Modes: 4
- Shutter/Strobe: Electronic
- Strobe Rate: 0 to 30 Hz
- Zoom: Motorized
- Control Protocols: DMX, RDM
- DMX Personalities: 4
- DMX Channels: 1, 2, 2, or 5
- Data Connectors: 3-pin and 5-pin XLR
- Input Voltage: 100 to 240 VAC, 50/60 Hz, auto-ranging
- Power Consumption: 222W at 120V, 231W at 208V, 230W at 230V
- Power Input: Seetronic powerKon IP65
- Power Output: Seetronic powerKon IP65
- Power Linking: 6 units at 120V, 10 units at 208V, 11 units at 230V
- Housing Material: Aluminum alloy and aluminum die-cast
- Exterior Color: Black
- Accessory Holder/Gel Frame Size: 7.5 in (191 mm)
- IP Rating: IP20, dry location
- Operating Temperature: -4°F to 113°F (-20°C to 45°C)
- Dimensions: 15.11 x 12.59 x 17.71 in (384 x 320 x 450 mm)
- Weight: 17.2 lb (7.9 kg)
- UPC: 781462217365
What's In The Box
- Ovation F-265WW fixture
- Seetronic powerKon IP65 power cable
- Gel frame
