Heavy-Duty Rigging Shackle for Truss and Stage Applications
The
Global Truss SHACKLE 5/8 is a heavy-duty galvanized steel shackle designed for safe and secure rigging in demanding environments like concerts, truss structures, and stage setups. With a 4.5-ton (9000 lb) load capacity, this shackle provides reliable performance where strength and durability are critical.
Global Truss SHACKLE 5/8 Competitive Differences
- Rated for up to 4.5 tons (9000 lbs) – ideal for high-load rigging
- Made in the U.S.A. by Columbus McKinnon – trusted manufacturing quality
- Galvanized steel construction for corrosion resistance and long-term use
- Versatile 5/8" size with 19mm pin and body diameter for compatibility with standard rigging hardware
- Wide 30mm jaw opening and 44mm bow width accommodate various attachments
Global Truss SHACKLE 5/8 Description
This
SHACKLE 5/8 from Global Truss is engineered for professional rigging needs in entertainment, construction, and industrial applications. It features a galvanized steel finish for superior protection against rust and wear, ensuring long-lasting strength even in challenging environments. With precise dimensions and a reliable pin system, this shackle is built for secure connections in overhead and structural setups.
Manufactured in the U.S.A. by Columbus McKinnon, a trusted name in rigging hardware, this component meets the high safety and performance standards required in stage lighting, truss systems, and load-bearing setups. Its robust design and build quality make it a go-to choice for professionals demanding safety and reliability.
SHACKLE 5/8 Features
- High-strength galvanized steel construction
- Corrosion-resistant finish (appearance may vary)
- Designed for truss and structural rigging applications
- Wide bow and jaw opening for flexible rigging setups
- Trusted U.S. manufacturing by Columbus McKinnon
SHACKLE 5/8 Specifications
- Maximum Load Capacity: 4.5 Tons / 9000 lbs
- Body Diameter: 0.75 in (19mm)
- Pin Diameter: 0.75 in (19mm)
- Jaw Opening: 1.18 in (30mm)
- Bow Inside Width: 1.73 in (44mm)
- Inside Height: 2.4 in (61mm)
- Ear Width: 1.65 in (42mm)
- Material: Galvanized Steel
- Finish: Galvanized (appearance may vary)
- Unit Weight: 1.33 lbs
Global SHACKLE5/8
(Global Truss SHACKLE-5/8)
