The mid-range of the MAX series, very powerful and always ready, the MAX 5000APS gives you fog the moment you need it.
Features:
MAXIMUM FOG OUTPUT UP TO 218 M3 (7,698 FT3) PER MINUTE, 100% DUTY CYCLE
DETACHABLE REMOTE CONTROL AND 8 M (26 FT) CABLE INCLUDED
APS™ (AUTOMATIC PURGING SYSTEM) TO PREVENT BUILD-UP AND CLOGGING
COMPATIBLE WITH DMX INTERFACE AND REMOTE CONTROL TIMER
VIRTUALLY NOISELESS, WITH THE FINEST FOG AND THE LONGEST HANGING TIME
VERY POWERFUL, MANUALLY ADJUSTABLE FOG OUTPUT
Specifications:
Maximum fog output per minute
218 m3 (7,698 ft3)
Fluid consumption
2.6 L (77 oz) per hour at 2.76 bar (40 psi)
Gas type
CO2 or N2
Gas consumption
2.25 kg (5 lb) per hour at 2.76 bar (40 psi)
Reservoir capacity
2.5 L (0.66 US gallon)
APS™ (Automatic Purging System)
Standard
Fog colour
Pure white
Particle size
0.5 - 0.7 micron
Warm-up time
8 minutes (maximum)
Fluid type
MDG Neutral
Operating voltage
115 or 230 VAC, 50/60 Hz single phase
Power consumption
1,415 W
DIMENSIONS
Length
61 cm (24”)
Width
28 cm (11”)
Height
30 cm (12”)
Weight
26 kg (56 lb)
Shipping weight
38 kg (85 lb) with flight case
Approval
CE certified and ETL field approved
MDG Fog MDGM5
(MDG MDG-Max 5000)
