Ultra-Portable Heritage D Series Digital Console
The
Midas HD96-AIR-CC-IP brings the power and pristine audio quality of the Heritage D series to a highly portable format. Designed for engineers who need the full capabilities of a touring-grade console in a compact footprint, the HD96-AIR offers up to 144 input channels, 123 time-aligned mix buses, and a stunning 21” multi-touch interface—all in a chassis under 17kg. It's ideal for fly dates, mobile productions, broadcast, and tight FOH spaces.
Midas HD96-AIR-CC-IP Competitive Differences
- All Heritage D power in a compact, lightweight (16.74 kg) format
- 21” ultra-bright HD touchscreen with multi-gesture control
Midas HD96-AIR-CC-IP Description
The
HD96-AIR is built on the HD96 platform, featuring Midas’ state-of-the-art 64-bit summing engine and uncompromising audio path with total phase coherence. Every signal path is delay-compensated to eliminate comb filtering and phase shift—ensuring crystal-clear mixes that scale from subtle studio nuance to high-SPL live environments.
Its fully adjustable 21” 1920x1080 capacitive touchscreen gives engineers rapid access to all key functions, from faders and channels to dynamics, routing, and EQ. With multi-touch gesture support, the HD96-AIR allows intuitive hands-on mixing and fast navigation during demanding live performances.
Despite its smaller size, the HD96-AIR supports the same high channel and bus counts as its larger siblings, offering 144 simultaneous input channels and 123 mix buses. Its space-efficient layout features user-assignable controls and a workflow optimized for fast-paced production environments—perfect for touring engineers, remote broadcasts, and tech-forward venues.
Model Features
- Up to 144 simultaneous input channels at 96kHz
- 123 phase-coherent, delay-compensated mix buses
- Award-winning Midas mic preamps
- 21” full HD (1920x1080) high-brightness touchscreen
- Advanced multi-gesture user interface for hands-on control
- 64-bit floating-point summing engine for superior audio resolution
- Fully portable with total system weight under 23 kg (with flight case)
Model Specifications
- Inputs: Up to 144 channels
- Mix Buses: 123 (phase-aligned and time-compensated)
- Touchscreen: 21” TFT HD display with capacitive multi-touch
- Sampling Rate: 96 kHz
- Processing: 64-bit floating-point summing
- Mic Preamps: Midas award-winning designs
- Dimensions: 8.29 x 18.29 x 31.72 in (21.05 x 46.45 x 80.58 cm)
- Weight: 36.9 lb (16.74 kg)
What's In The Box
- Midas HD96-AIR digital console
- Power cable
- User manual
Midas MDS-HD96-AIR-CC-IP
(Midas HD96-AIR-CC-IP)
