Heavy-Duty 6-Way Truss Junction for Modular Rigging Systems
The
ProX XT-F32JBOX is a 6-way universal truss junction box with a 3mm wall thickness, designed to offer exceptional strength and flexibility for modular rigging and truss configurations. Perfect for trade shows, permanent installations, or live production setups, it supports complex builds with industry-standard compatibility and TÃœV-certified construction.
ProX XT-F32JBOX Competitive Differences
- 6-way connection points allow for highly flexible rigging configurations
- Heavy-duty 3mm (0.11in) wall thickness for increased structural integrity
- TUV-certified aluminum welding ensures top safety and performance
- EN-AWT6 6082 aluminum for strength and reliability
- Compatible with most other F32 truss systems using standard conical connectors
- Precision-manufactured in-house by ProX
ProX XT-F32JBOX Description
The
XT-F32JBOX is a 6-way universal box junction designed for the ProX F32 truss system, offering maximum versatility in design and configuration. With six connection points, it allows for branching truss lines in multiple directions, making it an ideal component in complex lighting and rigging setups.
This rugged connector box is crafted with EN-AWT6 6082 aluminum and features TÃœV-certified welds, ensuring it meets strict safety and durability standards. The 3mm wall thickness (.11in) offers added strength for demanding applications, while maintaining compatibility with other trusses using standard conical connectors.
Whether you're working on a trade show booth, stage structure, or fixed installation, this truss junction delivers secure, stable, and adaptable support in any direction needed. Please note: connecting hardware is not included.
XT-F32JBOX Features
- 6-way universal truss junction for F32 series
- Material: EN-AWT6 6082 aluminum
- Heavy-duty 3mm tube wall thickness
- TUV-certified aluminum welding
- Tolerance-free standard conical connectors
- Lightweight yet strong for mobile or permanent use
- Manufactured in-house by ProX
- No connecting hardware included
XT-F32JBOX Specifications
- Truss series: F32
- Width: 11.42in (290mm)
- Height: 11.42in (290mm)
- Main tube diameter: 2in (50mm)
- Wall thickness: 0.11in (3mm)
- Brace diameter: 0.75in (20mm)
- Shipping dimensions: 12.00in x 12.00in x 3.00in
- Shipping weight: 6.00 lbs
- UPC: 019372409649
Pro X XT-F32 Junction BOX
(ProX F32 J-Box)
