RCF C5212-W

RCF C5212-W (RCF C-5212-W)
TWO-WAY PASSIVE SPEAKER

The C5212 W is a full range extremely versatile wide-dispersion two-way loudspeaker system for medium throw applications.

The high-frequency section is a constant directivity horn loaded to a 1.4” Neodymium compression driver with a 2.5” diaphragm assembly for smooth, wide dispersion.
The low-frequency transducer is a 12” woofer with a 3” voice coil.
The crossover is easily bypassed for bi-amp via a recessed changeover switch.

FEATURES
60° x 40° CMD (Constant Matching Design) constant directivity horn
1.4" neodymium compression driver with 2.5" diaphragm assembly
12" woofer with 3" voice coil
Dual-function design: built in passive crossover or external bi-amp
Rotatable Horn System for horizontal cabinet mounting applications
HF driver AMCDP (Active Mosfet Compression Driver Protection)
LICC (Low Impedance Compensated Crossover) network

APPLICATIONS
• Permanent Installations
• Main Reinforcement in small and medium spaces
• High-Level AV Playback
• Cluster configurations
• Live Music Reinforcement

PART NUMBER
• 13000112 white
• 13000044 black

ACOUSTICAL SPECIFICATIONS
Frequency Response -10 dB:54 Hz ÷ 20000 Hz
Max SPL @ 1m:132 dB
Horizontal coverage angle:90°
Vertical coverage angle:40°
Directivity index; Q:10
System Sensitivity:99 dB
Nominal Impedance:8 Ω
Power Handling:500 W
Peak Power Handling:2000 W
Recommended Amplifier:1000 W
Protections:Dynamic
Crossover frequencies:1200 Hz

TRANSDUCERS
Compression Driver:1.4"HF driver, 2.5" voice coil
Nominal Impedance:8 Ω
Input Power Rating:100 W AES
Sensitivity:111 dB
Woofer:12" woofer, 3" voice coil
Nominal Impedance:8 Ω
Input Power Rating:400 W AES
Sensitivity:98 dB
INPUT SECTION
Input connector:Speakon NL4 - Full range or Bi-Amp
Output connector:Speakon NL4

CABINET
Cabinet Material:15 mm birch plywood construction
Hardware:9 x M10 inserts
Handles:2 on side
Pole Mount/Cap:Yes
Grille:Custom perforated steel grille
Colour:Black, white, scratch resistant paint

PHYSICAL SPECIFICATIONS
Height:600 / 23.62 mm/inch
Width:364 / 14.33 mm/inch
Depth:385 / 15.16 mm/inch
Net Weight:23 / 50.7 kg/lbs
