High-Output Column Speaker for Live Sound and Installations
The
RCF NXW 44-A delivers premium sound reinforcement with a compact footprint and exceptional SPL. With
three high-power 10" neodymium woofers, a
3" titanium compression driver, and a
2,100W Class-D amplifier, it provides pristine, distortion-free output up to
135 dB SPL. Engineered for both portable and installed sound applications, the NXW 44-A combines
FiRPHASE processing and
Bass Motion Control (BMC) to ensure wide, consistent coverage and transparent frequency response down to 45 Hz.
RCF NXW 44-A Competitive Differences
- 135 dB SPL Output: Capable of delivering concert-level sound pressure
- 3x 10" Neodymium Woofers: Ultra-efficient LF drivers with fast transient response
- 3" Titanium Compression Driver: Wide 100° x 50° coverage with high intelligibility
- FiRPHASE DSP: Phase-coherent sound with zero latency
- Bass Motion Control (BMC): Woofer excursion management without phase distortion
- CMD Constant Matching Design Horn: Ensures even distribution without cabinet tilting
- PowerCON TRUE1 TOP: Rugged IP-rated power connectors with IN/OUT
- Flexible Deployment: Pole mountable, flyable, or ground stacked with 8 M8 & 8 Quick Lock rigging points
RCF NXW 44-A Description
The
NXW 44-A was purpose-built for DJs, bands, rental houses, and fixed installs needing a powerful, space-efficient sound solution. With a unique column format, this active speaker uses RCF's
CMD horn design to deliver focused 100° horizontal and 50° vertical coverage—ideal for challenging acoustic environments and long-throw applications.
Its
2100W bi-amplified Class-D amp (700W HF / 1400W LF) is integrated with RCF's top-tier transducer design, giving it exceptional power handling, low distortion, and extended dynamics.
FiRPHASE DSP filters and
Bass Motion Control enable unprecedented sound linearity and precise low-end management without introducing latency or phase shift.
Its rugged birch plywood cabinet, steel grille, and dual side handles make it ready for the road or a long-term installation. With
rigging points and quick lock mounts, the NXW 44-A can be flown or pole-mounted with ease. From mobile DJ setups to medium-scale live events, this speaker meets the demands of professionals who won’t compromise on sound quality.
NXW 44-A Features
- 2100W peak power (1400W LF + 700W HF) Class-D bi-amplifier
- 3 x 10" high-power neodymium woofers with 2.5" voice coils
- 1.4" exit, 3.0" voice coil titanium compression driver with CMD horn
- Max SPL: 135 dB
- Frequency response: 45 Hz – 20,000 Hz
- Coverage: 100° horizontal x 50° vertical
- Bass Motion Control DSP for woofer excursion management
- FiRPHASE technology for phase-correct audio with minimal latency
- Soft limiter with thermal, excursion, and RMS protections
- Combo XLR/TRS input, XLR output
- PowerCON TRUE1 TOP IN/OUT connectors (IP-rated)
- 8 x M8 and 8 x Quick Lock rigging points
- Baltic birch plywood cabinet with steel grille and ergonomic side handles
- 35 mm pole socket for standard stand/sub mounting
NXW 44-A Specifications
- Frequency Response: 45 Hz – 20,000 Hz
- Max SPL: 135 dB
- Coverage Angle: 100° (H) x 50° (V)
- Compression Driver: 1.4" exit / 3.0" v.c. titanium with neodymium magnet
- Woofers: 3 x 10" with 2.5" voice coils
- Crossover Frequency: 800 Hz
- Protections: Thermal, Excursion, RMS
- Limiter: Soft limiter
- Input Sensitivity: -2 dBu / +4 dBu
- Input Connectors: Combo XLR/Jack
- Output Connectors: XLR
- Cooling: Convection (no fan)
- Power Connections: PowerCON TRUE1 TOP IN/OUT
- Cabinet Material: Baltic birch plywood
- Rigging Hardware: 8 x M8, 8 x Quick Lock
- Handles: 2 side handles
- Pole Mount: 35 mm insert
- Grille: Steel
- Color: Black
- Dimensions (H x W x D): 42.52" x 11.71" x 14.69" (1080 x 297.5 x 373 mm)
- Weight: 69.56 lbs (31.55 kg)
- Shipping Dimensions: 15.75" x 43.9" x 12.87" (400 x 1115 x 327 mm)
- Shipping Weight: 74.19 lbs (33.65 kg)
RCF NXW 44-A
(RCF NXW44-A)
