High-Performance, Visually Striking Loudspeaker Array
The
VOID Acoustics Air Array is a visually stunning three-way bi-amped loudspeaker array designed for style-conscious venues and high-impact performance environments. With 14 proprietary drive units, integrated flying and mounting options, and a durable fibreglass Kevlar composite construction, this speaker array combines cutting-edge technology with a unique design to deliver unparalleled sound clarity and SPL performance for clubs, live events, and outdoor festivals.
VOID Acoustics Air Array Competitive Differences
- Striking visual design for style-driven venues
- 14 proprietary drive units for superior sound reproduction
- Fibreglass Kevlar composite construction for durability and weight reduction
- Customizable color options to match venue aesthetics
- Integrated flying and mounting systems for flexible installation
- Line-source design ensures consistent SPL across all distances
- High output levels with 3600 Watts LF power handling
VOID Acoustics Air Array Description
The VOID Acoustics Air Array is a top-tier mid-high loudspeaker system that brings together radical design and groundbreaking technology. With its sleek and sculpted appearance, the Air Array is perfect for style-conscious venues looking to make a statement. It features a 90° horizontal by 45° vertical coverage pattern, allowing for even sound distribution across the venue while maintaining constant SPL and coherent phase at all distances.
This loudspeaker features four high-powered 12" low-frequency drivers delivering 3600 watts of RMS power, combined with a heatsink cooling system for maximum reliability. In the midrange, four 3" compression drivers with 6" diaphragms ensure clarity down to 500Hz, while six 1" compression drivers extend the high frequencies up to 26kHz. Advanced path length compensation and waveguide design eliminate destructive interference, ensuring seamless audio output across the frequency range.
The VOID Acoustics Air Array can be ground-stacked on subwoofers or flown using its integrated rigging system, providing flexibility for both indoor and outdoor installations. Its fibreglass and Kevlar composite enclosure is lightweight yet durable, with a standard gloss red finish and custom color options available for those seeking a bespoke aesthetic.
VOID Acoustics Air Array Features
- Striking design for style-led environments
- 14 proprietary drivers:
- 4 x 12" low-frequency drivers
- 4 x 3" midrange compression drivers
- 6 x 1" high-frequency compression drivers
- Controlled 90° horizontal by 45° vertical dispersion
- Fibreglass Kevlar composite enclosure for durability and reduced weight
- Optional custom colors and finishes
- Stack mountable or flyable with integrated rigging system
- SpeakON NL8 connectors for secure signal transmission
- Supplied with a ground stack frame or flying bracket (optional)
VOID Acoustics Air Array Specifications
- Frequency Response: 90 Hz - 26 kHz ±3dB
- Efficiency:
- LF: 111 dB 1W/1m
- MF: 114 dB 1W/1m
- HF: 116 dB 1W/1m
- Crossover Point: Preset via dedicated processor
- Impedance:
- LF: 2 x 4 ohms
- MF: 2 x 4 ohms
- HF: 2 x 5.33 ohms
- Power Handling:
- LF: 3600 Watts RMS
- MF: 1000 Watts RMS
- HF: 480 Watts RMS
- Maximum Output: 143 dB continuous, 149 dB peak
- Driver Configuration:
- 4 x 12" LF drivers
- 4 x 3" MF compression drivers
- 6 x 1" HF compression drivers
- Dispersion: 90° horizontal, 45° vertical
- Connectors: 2 x 8-pole SpeakON NL8
- Dimensions (HxWxD): 48.8" x 37.1" x 32.0" (1240mm x 944mm x 813mm)
- Weight: 319 lbs (144.8 kg) including stand
- Enclosure: Fibreglass Kevlar composite
- Rigging: Stack mounted or proprietary flying system
- Finish: Smooth cellulose with standard gloss red or custom colors
Void Air-Array
(VOID Acoustics Air array)
