Yamaha MGP24XA | 24-Input Mixer with 16 D-PRE Mic ...
$2,069.99
The Yamaha MGP24X A combines the familiar hands-on workflow of an analog mixer with integrated digital effects, dynamics, and recording capabilities. Its 16 microphone inputs, four stereo input channels, flexible bus architecture, and USB device recorder make it a practical mixing solution for live performances, presentations, worship services, event production, and permanent installations.
The Yamaha MGP24X A provides 24 line inputs arranged as 16 mono input channels and four stereo input channels. Its 16 balanced XLR microphone inputs accommodate vocals, instruments, wireless systems, and other sources while providing independent 48V phantom power and high-pass filtering on each microphone channel.
Yamaha discrete Class-A D-PRE microphone preamps are designed to capture incoming signals with clarity and natural tonal detail. X-pressive EQ provides responsive frequency shaping, while eight one-knob compressors make it easier to control vocal and instrument dynamics without requiring complicated menus or external processors.
Two independent onboard effects engines expand the console’s sound-shaping capabilities. The REV-X processor supplies high-resolution reverb programs, while the SPX processor provides a selection of modulation, delay, reverb, and combination effects. Both processors can be used at the same time for more flexible live mixing.
Four group buses, six AUX sends, two matrix outputs, a mono output, master compression, graphic EQ, and direct USB recording and playback make the mixer suitable for live bands, DJs, corporate events, schools, houses of worship, performance venues, and installed audio systems.
| Brand | Yamaha |
| Name | Yamaha MGP24XA |
| Primary Category | Analog Mixing Console |
| Build Material | Hybrid analog mixing console with universal internal power supply |
| Dimensions | 32.2 x 6.7 x 22.2 in (819 x 169 x 565 mm) mm |
| Included Accessories | Universal internal power supply |
| Weight | 34.2 lb (15.5 kg) kg |
| Channels | 24 line inputs consisting of 16 mono and four stereo channels channels |
| Control Interfaces | 16 discrete Class-A D-PRE microphone preamps, eight one-knob compressors on channels 9–16, X-pressive three-band EQ on mono input channels |
| Frequency Response | 20Hz–20kHz, +0.5/-1.0dB Hz |
| Power Consumption | 76W maximum W |
| Voltage Range | 100–240V AC, 50/60Hz V |
