The Yamaha MGP32X A combines hands-on analog operation with integrated digital processing for medium-size live productions and installed audio systems. It provides 24 microphone inputs, four stereo input channels, flexible group and auxiliary routing, dual effects processors, and direct USB recording and playback.
The Yamaha MGP32X A offers the immediate control of a traditional analog console with Yamaha digital processing integrated behind the mixing surface. Its 32-input capacity includes 24 mono microphone and line channels plus four stereo input channels, providing ample connectivity for vocals, instruments, wireless microphones, playback equipment, and other event sources.
Each microphone channel features a discrete Class-A D-PRE preamp, independently switchable 48V phantom power, and a 100Hz high-pass filter. X-pressive EQ supports musical frequency adjustment, while 16 one-knob compressors make it easier to control vocals and instruments without requiring complicated parameter adjustments or external dynamics processors.
The full-size control surface provides dedicated channel controls for efficient hands-on mixing. Four group buses, four AUX sends, two FX sends switchable to AUX 5 and AUX 6, two matrix outputs, and a dedicated mono output support monitor mixes, recording feeds, delay speakers, subwoofers, and multi-zone sound systems.
Dual onboard effects include Yamaha REV-X reverb with eight programs and an SPX multi-effects processor with 16 programs. USB device recording and playback, master compression, graphic EQ, Priority Ducker, and Leveler processing make the console well suited for live bands, corporate events, houses of worship, schools, party venues, and permanent sound installations.
| Brand | Yamaha |
| Name | Yamaha MGP32XA |
| Primary Category | Hybrid analog mixing console |
| Build Material | Hybrid analog mixing console with integrated digital processing |
| Dimensions | 40.4 x 6.7 x 22.2 in (1027 x 169 x 565 mm) mm |
| Included Accessories | USB device recording and playback capability |
| Weight | 41.9 lb (19 kg) kg |
| Channels | 32 line inputs consisting of 24 mono and four stereo channels |
| Control Interfaces | Full-size control surface with dedicated channel controls |
| Onboard DSP | Dual effects processors: REV-X with 8 reverb programs and SPX with 16 multi-effects programs |
| Preset Storage | 16 one-knob compressors on channels 9–24 |
| Frequency Response | 20Hz–20kHz, +0.5/-1.0dB Hz |
| Power Consumption | 86W maximum W |
| Power Rating | 24 discrete Class-A D-PRE microphone preamps |
| Voltage Range | 100–240V AC, 50/60Hz volts |
| Warranty Length | Not specified years |
