Yamaha MGX12V B

18-Channel Digital Mixer with 4K HDMI Capture, Bluetooth & FX

$899.99 In Stock!
$0 Tax $0 Shipping $138 Back or Join VIP for upfront discounts.

(more)

Hybrid Audio & Video Mixing Power

The Yamaha MGX12V B reimagines digital mixing for modern creators—offering premium Yamaha sound, versatile connectivity, and integrated 4K video capture. This 18-channel console is compact yet feature-rich, making it perfect for podcasting, live streaming, event production, and studio work.

Why Choose the MGX12V B?

  • HDMI-USB integration for 4K60 capture and passthrough
  • MGX preamps with 86 dB of gain for crystal-clear signal
  • Auto Gain, Clip Safe, and scene recall for foolproof performance
  • Bundled with Steinberg’s Cubase AI, WaveLab Cast LE & FX Suite

Flexible Workflow, Stunning Results

With a 4.3” touchscreen, tactile faders, and assignable control knobs, the MGX12V B offers intuitive hands-on control. Whether managing live sound in a venue or switching scenes in a podcast stream, everything is at your fingertips—including eight customizable sound pads and a wide range of input effects like reverb, delay, compression, EQ, and amp simulation. The HDMI interface allows you to pass video through the mixer while simultaneously capturing it to a computer—perfect for livestream setups, hybrid conferences, or performance capture.

Top Features:

  • Touchscreen GUI with 5 control knobs and intuitive layout
  • HDMI input + passthrough for integrating external video (4K60)
  • Bluetooth 5.0 audio input for seamless wireless playback
  • microSD slot for 16-track recording / 2-track playback
  • USB Main: 18x18 I/O @ 96 kHz, USB Sub: 2x2 I/O @ 48 kHz
  • Assignable sound pads, dual modes (Simple/Standard), and FX processing
  • Includes Steinberg Cubase AI, WaveLab Cast LE, Basic FX Suite, Steinberg Plus library

Specs Overview:

  • Inputs: 8x Combo (XLR-1/4"), 4x 1/4" TRS, 4x RCA
  • Outputs: 2x XLR, 8x 1/4", 4x Headphones
  • Built-In FX: 13 Types (including REV-X Reverb, Delay, Voice Changer)
  • HDMI: In/Thru – with real-time passthrough and USB capture
  • Max Recording: 22 Tracks via USB, 16 via microSD
  • Audio Quality: 125 dB Dynamic Range, < 0.002% THD
  • Weight: 9 lb (4.1 kg)
  • Dimensions: 13.2 x 12.5 x 3.8 in

What’s in the Box:

  • Yamaha MGX12V B Mixer (Black)
  • AC Power Adapter
  • Steinberg Software License (Cubase AI, WaveLab Cast LE, FX Suite)
  • Start Guide & Safety Guide

Yamaha MGX12V B (Yamaha MGX12V-B)

Brand Yamaha
Name Yamaha MGX12V B | 18-Channel Digital Mixer with 4K HDMI Capture, Bluetooth & FX | USB Audio Interface – Black

Channels 18

Connectivity Protocols HDMI input + passthrough (4K60), Bluetooth 5.0, USB 18x18 I/O @ 96 kHz, USB 2x2 I/O @ 48 kHz, microSD slot

Dimensions 13.2 x 12.5 x 3.8 in inches
Included Accessories AC Power Adapter, Steinberg Software License (Cubase AI, WaveLab Cast LE, FX Suite), Start Guide & Safety Guide
Weight 9 lb (4.1 kg) kg

Screen / Display 4.3” touchscreen inches

Choose the Yamaha MGX12V B for its seamless integration of audio and video mixing, versatile connectivity options, intuitive touchscreen controls, and bundled professional software, enabling creators to produce high-quality live streams, podcasts, and event productions with ease.

The mixer captures and processes up to 18 audio channels with MGX preamps and built-in effects, while simultaneously capturing 4K video via HDMI input and passthrough. Bluetooth 5.0 allows wireless audio playback, and the touchscreen interface provides hands-on control for live mixing and scene management.

The MGX12V B uniquely combines high-quality digital audio mixing with integrated 4K HDMI video capture and passthrough, Bluetooth 5.0 wireless audio input, and a touchscreen interface, making it ideal for hybrid audio-video production workflows.

Includes HDMI-USB integration for 4K60 capture and passthrough, MGX preamps with 86 dB gain, Auto Gain, Clip Safe, scene recall, 4.3” touchscreen with tactile faders and assignable knobs, eight customizable sound pads, 13 built-in FX types including reverb, delay, compression, EQ, and amp simulation. Supports 16-track recording via microSD and 22-track via USB.

Inputs: 8x Combo (XLR-1/4"), 4x 1/4" TRS, 4x RCA. Outputs: 2x XLR, 8x 1/4", 4x Headphones. Audio Quality: 125 dB Dynamic Range, < 0.002% THD. Weight: 9 lb (4.1 kg). Dimensions: 13.2 x 12.5 x 3.8 in.
