Passive Loudspeaker Distribution System
The
Zero Ohm ZOHM-2K-2 is a compact, 2-channel passive interface that allows amplifiers to connect to multiple loudspeakers in parallel without overloading due to impedance. This system removes the need for 70V/100V transformers and maintains full-range performance even over extremely long cable runs — making it a powerful tool for scalable audio distribution.
Zero Ohm ZOHM-2K-2 Competitive Differences
- 2000W per channel passive system for low-impedance speaker arrays
- Sub-1Ω compatibility with transformer-free parallel wiring
Zero Ohm ZOHM-2K-2 Description
Known as the “2K2 Renegade” and formerly model MS-2R, the
ZOHM-2K-2 is built for audio professionals who need flexibility, efficiency, and clarity in their distributed sound systems. Designed for passive use, this device connects between any amplifier and multiple loudspeakers — supporting ultra-low impedances down to 0.1 ohms without stressing the amplifier.
Perfect for houses of worship, large venues, and multi-zone systems, the ZOHM-2K-2 works with speakers of any impedance (2Ω, 4Ω, 8Ω, or 16Ω), and delivers full-range audio from 20Hz to 20kHz. This passive solution also maintains phase accuracy across all channels, making it ideal for high-fidelity installations that span large distances.
Made in Canada and housed in a durable rackmount chassis, the
Zero Ohm ZOHM-2K-2 is built to simplify the most complex system designs — with no digital processing, no transformers, and no compromise in sound quality.
Model Features
- Passive 2-channel interface with zero-ohm compatibility
- Eliminates the need for 70V/100V transformer systems
- Allows parallel connection of multiple loudspeakers
- Compatible with 2Ω, 4Ω, 8Ω, and 16Ω speaker loads
- Full-range frequency response: 20Hz – 20kHz
- Maintains output phase alignment across amplifiers
Model Specifications
- Max Power Handling: 2000W per channel
- Frequency Response: 20Hz – 20kHz
- Min. Output Impedance: 0.1 Ohms
- Input Connectors: Neutrik NL4 (Pin 2+ / 2−)
- Output Connectors: Neutrik NL4 (Pin 1+ / 1−)
- Dimensions (H x W x D): 65.1 x 479.4 x 149.2 mm (with rack ears)
- Weight: 3.2 kg
- Shipping Weight: 4 kg
- Country of Origin: Canada
What's In The Box
- Main unit
- Rack ears (pre-installed)
- Quick start guide
Zero Ohm ZOHM-2K-2
(Zero Ohm ZOHM2K2)
