Behringer WING BK

Digital Mixing Console

Behringer WING BK is a high-performance digital mixing console designed for front-of-house, monitor mixing, and studio applications. With flexible stereo channel architecture, massive I/O capability, and an intuitive touchscreen interface, it delivers unmatched control and sound quality for demanding audio professionals.

Behringer WING BK Competitive Differences

• 48 fully configurable stereo channels with mono, stereo, or M/S operation
• 28 stereo buses with immersive in-ear monitoring capability
• 10.1" multi-touch screen with dedicated rotary controls for fast workflow
• 374 inputs and 376 outputs for extreme routing flexibility
• 16 stereo FX engines with 80+ premium effect emulations

Behringer WING BK Description

The Behringer WING BK redefines digital mixing with its innovative stereo channel concept, allowing engineers to configure channels as mono, stereo, or mid/side without sacrificing channel count or performance. This flexibility makes it ideal for complex live productions, broadcast environments, and studio sessions.

Equipped with 8 Midas PRO preamps and outputs, the WING BK delivers exceptional audio quality with wide dynamic range and low noise performance. The console features 24 motorized 100 mm faders, a dedicated channel editing section, and a large 10.1" capacitive touchscreen for fast, intuitive control over every parameter.

Its extensive I/O capabilities include 374 inputs and 376 outputs, AES50 connectivity for stageboxes, StageConnect for simplified cabling, and a built-in 48x48 USB audio interface for seamless DAW integration. The dual SD card recorder supports up to 64-track recording, making virtual soundchecks and live playback effortless.

With over 80 onboard effects inspired by legendary studio hardware, along with 16 stereo FX engines and 40-bit internal processing, the WING BK eliminates the need for external processors while maintaining pristine audio fidelity. Its customizable control surface and advanced automation features make it a powerful centerpiece for any professional audio setup.

WING BK Features

• 48 stereo channels configurable as mono, stereo, or M/S
• 28 stereo buses with full processing and inserts
• 8 Midas PRO mic preamps and 8 outputs
• 24 motorized 100 mm faders across 3 sections
• 10.1" capacitive touchscreen with adjustable angle
• 374 inputs and 376 outputs for complex routing
• 3 AES50 ports with 144x144 channels and ultra-low latency
• StageConnect 32-channel bidirectional audio over XLR
• 48x48 USB audio interface for DAW integration
• Dual SD card recorder with up to 64 tracks
• 16 stereo FX engines with 80+ effect algorithms
• Custom control section with assignable buttons and encoders
• GPIO, MIDI, AES/EBU, and headphone outputs included

WING BK Specifications

• Frequency Response: 10 Hz – 20 kHz
• Dynamic Range (Analog In to Out): 111 dB (XLR), 108 dB (Aux)
• A/D Dynamic Range: 112 dB (XLR), 110 dB (Aux)
• D/A Dynamic Range: 118 dB (XLR), 112 dB (Aux)
• Main Display: 10.1" TFT LCD, 1280 x 800, multi-touch
• Faders: 24 motorized 100 mm
• USB Audio Interface: 48x48 channels
• Recorder: Dual SD card, up to 64 tracks
• Power Supply: 100–240 VAC, auto-ranging
• Power Consumption: 130 W
• Dimensions: 34.3 x 22.6 x 7.9 in (870 x 575 x 201 mm)
• Weight: 52.8 lb (24 kg)

What's In The Box

• Behringer WING BK digital mixing console
• Power cable
• Quick start guide

Behringer WING BK (Behringer WING-BK)
