Rugged Outdoor Wireless DMX Transceiver with RDM and Long-Range Reliability
The
Blizzard Lighting Lightcaster CRMX GOAT IP is an IP65-rated wireless DMX transceiver designed for professional lighting control in any environment. Featuring ultra-stable 2.4GHz Adaptive Frequency Hopping Spread Spectrum (AFHSS) technology, this unit ensures rock-solid DMX and RDM signal transmission up to 1,000 meters (3,280 feet), even in high-interference environments.
Blizzard Lighting Lightcaster CRMX GOAT IP Competitive Differences
- IP65 Rated: Fully weatherproof housing for reliable outdoor use in all conditions
- 2.4GHz Wireless DMX: Supports both DMX and RDM over a single universe per unit
- Massive Range: Up to 1,000-meter (3,280 ft) wireless range with high-gain 5dBi antenna
- Effortless Switching: Seamlessly toggle between transmit and receive modes
- High Sensitivity Receiver: -98 dBm receiver sensitivity for stable long-distance reception
- High Power Transmission: 100mW output ensures strong signal integrity across large venues
- True Outdoor Power: Equipped with powerCON® TRUE1 power input
Blizzard Lighting Lightcaster CRMX GOAT IP Description
Designed for permanent installs and mobile production where wireless reliability is critical, the
Lightcaster CRMX GOAT IP from Blizzard Lighting delivers best-in-class wireless DMX and RDM transmission. With its weather-sealed IP65 rating, this unit thrives in rain, dust, and rugged terrain, making it perfect for outdoor festivals, architectural lighting, and temporary outdoor events.
Thanks to CRMX technology over the 2.4GHz band and AFHSS (Adaptive Frequency Hopping Spread Spectrum), the GOAT IP avoids interference from Wi-Fi and other wireless devices, ensuring a rock-solid connection over distances up to 1,000 meters. This makes it ideal for demanding installations and large-scale productions.
The unit supports one DMX universe per transceiver but is scalable up to 16 universes using additional transmitters. It features high-performance 5-pin DMX in/out connectors, a 5dBi antenna, and a powerCON® TRUE1 input for professional-grade power reliability.
Lightcaster CRMX GOAT IP Features
- IP65 weatherproof enclosure for indoor or outdoor use
- 2.4GHz wireless transmission with Adaptive Frequency Hopping (AFHSS)
- CRMX technology supports both DMX and RDM protocols
- Up to 1,000-meter (3,280 ft) wireless range
- 100mW transmitter power output
- Ultra-sensitive receiver with -98 dBm capability
- Supports 1 universe per transmitter; scalable up to 16 universes
- Switchable transmit/receive modes
- High-quality 5dBi antenna included
- 5-pin DMX input and output connectors
- Locking powerCON® TRUE1 input for secure power connection
Lightcaster CRMX GOAT IP Specifications
- Wireless Protocol: 2.4GHz CRMX with RDM support
- Range: Up to 1,000 meters (3,280 ft)
- Transmitter Power: 100mW
- Receiver Sensitivity: -98 dBm
- Control Capacity: 1 DMX universe per unit, up to 16 universes with multiple transmitters
- Power Input: powerCON® TRUE1
- Connectors: 5-pin DMX In/Out
- Enclosure Rating: IP65 (outdoor-rated)
- Antenna: 5dBi detachable
- Dimensions (Single Pack): 12" L x 8.5" W x 5" H
- Weight: 4.5 lbs
Blizzard CRMX GOAT IP
(Blizzard Lighting Lightcaster CRMX GOAT IP)
