Reliable UHF Wireless Bodypack System for Versatile Performance
The
CAD WX1000BP is a professional-grade, frequency-agile UHF wireless bodypack system designed for demanding live sound environments. With 100 selectable channels in the 510–570 MHz band, IR sync, and auto-scan functionality, it ensures rock-solid signal clarity and flexibility for performers, speakers, and musicians. Ideal for stage, worship, fitness, and broadcast use, this system includes a lavalier mic, head-worn mic, and guitar cable for unmatched versatility.
CAD WX1000BP Competitive Differences
- 100 frequency-agile UHF channels for interference-free operation
- Auto-scan and IR sync for quick and seamless setup
- Up to 20 systems can operate simultaneously
- All-metal chassis with included rackmount hardware for durability
- Includes three connection options: lavalier mic, headset mic, and instrument cable
- 295 ft (90 m) transmission range for freedom of movement
- Over 12 hours of runtime using just 2 AA batteries
CAD WX1000BP Description
Built for professional performance, the
CAD WX1000BP wireless bodypack system delivers consistent, high-quality audio in a wide range of applications—from live music to public speaking. The system’s frequency-agile design provides 100 UHF channels, while the auto-scan and IR sync functions simplify pairing and prevent dropouts.
Designed with an all-metal construction, both the transmitter and receiver are rugged enough for the rigors of touring and live production. The transmitter runs for more than 12 hours on just two AA batteries, and battery level indicators are available on both units. Included rack mounting hardware and antenna relocation kits make installation a breeze.
For ultimate flexibility, the package includes a lavalier microphone, a head-worn microphone, and an instrument cable—making it perfect for vocalists, presenters, instructors, and musicians alike.
WX1000BP Features
- 100 frequency-agile UHF channels (510–570 MHz)
- Auto-scan and IR sync for easy channel setup
- Includes head-worn mic, lavalier mic, and guitar/instrument cable
- Rugged all-metal housing on transmitter and receiver
- Transmit power: 10 mW
- Up to 295 ft (90 m) operating range
- Battery-powered transmitter: 2 x AA with over 12-hour runtime
- Low battery indicators on both transmitter and receiver
- Rackmount kit and antenna relocation accessories included
- 2-year manufacturer warranty
WX1000BP Specifications
- Receiver Frequency Range: 510 MHz – 570 MHz
- Audio Frequency Response: 30 Hz – 18 kHz
- Dynamic Range: >100 dB
- Outputs: 1 x 1/4" (6.3 mm), 1 x XLRM
- Bodypack Transmitter Frequency Response: 30 Hz – 18 kHz
- Transmit Power: 10 mW
- Connector Type: TA4F
- Power: 2 x AA batteries (up to 12+ hours of operation)
- Package Weight: 3.3 lbs
- Package Dimensions: 16” x 12.1” x 2.8”
CAD WX1000BP
(CAD WX1000BP-U)
