Multi-Effect LED Blinder and Strobe
Chauvet DJ Shocker Panel FX is a compact but powerful LED fixture that functions as a blinder, strobe, or wide-angle wash. Packed with 512 LEDs and 16 individually controllable zones, it offers impressive programming flexibility for DJs, clubs, and production environments that demand fast transitions and bold visual impact. Its versatile design makes it a go-to fixture for eye-catching effects and immersive light shows.
Chauvet DJ Shocker Panel FX Competitive Differences
- 16-zone pixel mapping for advanced effect control
- High-output RGB and cool white LED arrays with built-in macros
Chauvet DJ Shocker Panel FX Description
The
Chauvet DJ Shocker Panel FX is built for lighting designers and performers who need punch, speed, and flexibility. With a combination of 480 tri-color RGB LEDs and 32 cool white LEDs, this unit excels as a blinder, strobe, or vibrant wash fixture. It delivers over 13,600 lumens and a wide beam spread, making it suitable for large events or tight stages alike.
With 16 zones (8 RGB + 8 white) of pixel control, users can create dynamic chase effects, eye candy visuals, or synchronized scenes across multiple units. Choose from multiple DMX channel modes — up to 47 channels — or use built-in macros for quick deployment without programming.
Designed with mobile setups in mind, the Shocker Panel FX features an all-metal housing, powerCON-compatible connections for power linking, and easy transport compatibility with the CHS-25 VIP gear bag. Whether hung, mounted, or used as a floor fixture, it adds intense energy and professional polish to any light show.
Model Features
- Blinder, strobe, and wash functionality in one fixture
- 512 LEDs: 480 RGB + 32 cool white
- 16-zone pixel mapping for advanced programming
- Multiple DMX modes (8, 18, 34, or 47 channels)
- Rugged all-metal housing
- PowerCON-compatible power input/output
Model Specifications
- DMX Channels: 8, 18, 34, or 47
- DMX Connectors: 3-pin and 5-pin XLR
- Light Source: 480x RGB LEDs (2W) + 32x CW LEDs (1.1W)
- Beam Angle: 119°
- Field Angle: 158°
- Illuminance: 1,131 lux @ 2m
- Lumens: 13,626
- Strobe Rate: 0 to 20 Hz
- Input Voltage: 100–240 VAC, 50/60 Hz (auto-ranging)
- Power Consumption: 296W, 2.5A @ 120V | 281W, 1.3A @ 230V
- Power Linking: 5 units @ 120V; 10 units @ 230V
- Dimensions: 12.63 x 4.3 x 6.7 in (310 x 110 x 170 mm)
- Weight: 8.6 lb (3.9 kg)
- Approvals: CE, UKCA, RoHS
What's In The Box
- Shocker Panel FX
- Power cord
- Quick Reference Guide
Chauvet Shocker Panel FX V2
(Chauvet DJ Shocker Panel FX MKII)
