IP65 LED Strobe/Wash Hybrid Fixture
The
Chauvet Pro Color STRIKE M V2 is a powerful hybrid strobe and wash lighting fixture built to withstand the demands of touring and outdoor production. With its IP65 rating and wide 180° motorized tilt, it delivers vibrant color washes and dynamic strobe effects in any environment—rain or shine.
Chauvet Pro Color STRIKE M V2 Competitive Differences
- 14 RGB and 28 white strobe zones for advanced pixel control
- IP65-rated housing with built-in alignment pins for seamless arrays
Chauvet Pro Color STRIKE M V2 Description
The
Color STRIKE M V2 by Chauvet Professional is a feature-packed strobe and wash fixture engineered for large-scale productions, stadium shows, and demanding event installs. Its hybrid design combines bold white strobe tubes with a 14-zone RGB LED face, delivering an unmatched blend of punchy strobe effects and vibrant color washes.
With a massive 180° motorized tilt and 16-bit dimming, this fixture is as smooth as it is powerful. Adjustable PWM ensures flicker-free performance on camera, while RDM and a USB port allow quick remote updates and system management. Control options include DMX, ArtNet, and sACN, making integration into professional rigs simple and efficient.
Multiple DMX modes (up to 97 channels) provide deep control over every segment, or use the built-in macros for quick, impactful effects. Designed with production flexibility in mind, the repositionable yoke enables vertical or horizontal rigging, and alignment pins make it easy to create straight linear arrays every time.
Model Features
- Hybrid strobe and color wash fixture
- Motorized 180° tilt range
- 14 pixel-mapped RGB zones and 28 white strobe zones
- 16-bit dimming for smooth fades
- Built-in effect macros and adjustable PWM for camera use
- Supports DMX, ArtNet, and sACN
- IP65-rated for indoor/outdoor use
- Built-in alignment pins for perfect fixture alignment
- RDM and USB port for remote updates
- Yoke supports horizontal or vertical mounting
Model Specifications
- Type: Hybrid LED Strobe/Wash
- LEDs: 896 Tri-color (0.784W), 432 Cool White (1.56W)
- Control Modes: DMX, ArtNet, sACN
- DMX Modes: 8, 11, 13, 24, 30, 47, 74, 97 channels
- Illuminance: 231 lux (plate), 1432 lux (beam), 1591 lux (combined)
- Beam Angle: 50°–123°
- Power Consumption: 720W, 7.14 A @ 100V
- Power Supply: Seetronic Powerkon IP65 (cable included)
- Display: OLED
- Height: 12.3 in (312 mm)
- Width: 16.02 in (407 mm)
- Depth: 6.9 in (175 mm)
- Weight: 26.6 lb (12.1 kg)
- Manufacturer Part Number: COLORSTRIKEMV2
What's In The Box
- Color STRIKE M V2 fixture
- Mounting yoke
- Powerkon IP65 power cable
- User manual
Chauvet Color Strike M
(Chauvet Pro Color-Strike M MK2)
