JMaz Phantom PixelWash 1930Z
$1,499.95
The JMAZ Phantom PixelWash 1930Z is a 280W LED moving head zoom/wash with RGBW capabilities. Includes built-in wireless DMX technology and individually pixel control LEDs.
Specifications
Light Source
Source: 19 x 30W RGBW LEDs & 0.5W Ring SMDs
Color System
Color LEDs: RGBW
Color SMDs: RGB
Body
Hardware On-Board: sockets for quick-Lock Omega bracket
Pan Angle: 630
Title Angle: 270
Pan/Tilt Resolution: 8 / 16 Bit
Feedback: Scan position memory, auto reposition after unexpected movement
Body: High Temperature Engineered Plastic and Cast Aluminum Casing
Body Colour: Black
Electronics
Dimmer: 0-100% Linear Dimmer
Electrical
Mains Power Supply:AC Mains
Max Power Consumption: 570W
Input Voltage: AC90-260V 50HZ/60HZ
Optics
Zoom: 6 to 60
Dynamic Effect
Ring Tron Effect Overlay
Strobe Effect
Wash Effect
Control
Protocols: DMX512, W-DMX, Wi-MAZ Wireless DMX
DMX Channels: 13/15 Channel Modes
Wireless Control: Wi-MAZ Wireless DMX, W-DMX, RF Remote
Display: 2.4?" TFT LCD Display
Firmware Upgrade: Yes, USB-DMX Interface, not included.
Physical
IP Rating: 20
Cooling: Fan
Pan/Tilt:8/16 bit smooth
Data Connection: DMX, Wireless DMX
Power Connection: Power-CON
Dimensions: 16.2?" x 11.1?" x 16.4?"
Weight: 29 lbs
Box Content
1 x Phantom Pixelwash 1930Z
1 x User Manual
2 x Omega Brackets
1 x 3ft 3-pin DMX Chord
1 x 3ft PowerCON Chord
1 x RF Remote
| Brand | JMAZ |
| Name | JMAZ Phantom PixelWash 1930Z |
| Build Material | High Temperature Engineered Plastic and Cast Aluminum Casing |
| Dimensions | 16.2" x 11.1" x 16.4" inches |
| Included Accessories | 1 x User Manual, 2 x Omega Brackets, 1 x 3ft 3-pin DMX Chord, 1 x 3ft PowerCON Chord, 1 x RF Remote |
| Mounting Options | Sockets for quick-Lock Omega bracket |
| Weight | 29 lbs lbs |
| Connectivity Protocols | DMX512, W-DMX, Wi-MAZ Wireless DMX |
| IP Rating | 20 |
| LED Type | 19 x 30W RGBW LEDs & 0.5W Ring SMDs |
| Power Consumption | 570W max W |
| Power Rating | 280W W |
| Voltage Range | AC90-260V 50HZ/60HZ V |
| Wattage | 570W max power consumption W |
| Control Interfaces | DMX, Wireless DMX, RF Remote |
| Firmware Updates | Yes, USB-DMX Interface (not included) |
| Preset Storage | Scan position memory, auto reposition after unexpected movement |
| Screen / Display | 2.4" TFT LCD Display |
| DMX Channel Modes | 13/15 Channel Modes |
| Wireless DMX | Wi-MAZ Wireless DMX, W-DMX |
