Max I/O Capacity 5 x Input / 4 x Output Number of Analog Input Channels 4 (2 Mono / 2 Stereo) Number of Mic Preamps 2 Number of Analog Output Channels 3 Faders & Level Adjustment 9 x Non-Motorized Channel Knob Built-In Effects 1 x De-Esser 1 x Reverb 1 x Delay Analog Inputs 2x Combo XLR-1/4" 3-Pin Balanced/Unbalanced Mic/Line/Hi-Z Input 2x 1/4" TRS Balanced/Unbalanced Line Input (1 Stereo Pair) 1x 1/8" / 3.5 mm TRS Stereo Line Input Show Less Analog Outputs 2x 1/4" TRS Balanced/Unbalanced Line Output (1 Stereo Pair, Post-Fader) 2x 1/4" TRS Stereo Headphone Output (Post-Fader) Digital I/O 1x RJ45 Ethernet Input/Output (I/O, Link) USB I/O 1x USB-C (Audio Playback, Audio Streaming, Host Connection, Recording) Wireless Bluetooth *Built-In Rack Mountable No Mixer Max I/O Capacity 5 x Input / 4 x Output Number of Analog Input Channels 4 (2 Mono / 2 Stereo) Number of Mic Preamps 2 Number of Analog Output Channels 3 Mix Routing 2 x Mono Bus 3 x Stereo Bus Groups No Presets 3 x Preset (Factory) Display 7" LCD Touchscreen Display Resolution/Color RGB Color Faders & Level Adjustment 9 x Non-Motorized Channel Knob Signal Processing Dynamic Processing Compressor, Gate EQ 3-Band Parametric Filters 1 x High-Pass Solo/Mute Solo, Mute per Input Channel Channel Output/Source Monitoring AFL Built-In Effects 1 x De-Esser 1 x Reverb 1 x Delay Real Time Analyzer No Automatic Mic Mixing Yes Digital Audio Sample Rates 48 kHz Bit Depth 24-Bit Latency 3 ms Connectivity Analog Inputs 2x Combo XLR-1/4" 3-Pin Balanced/Unbalanced Mic/Line/Hi-Z Input 2x 1/4" TRS Balanced/Unbalanced Line Input (1 Stereo Pair) 1x 1/8" / 3.5 mm TRS Stereo Line Input Analog Outputs 2x 1/4" TRS Balanced/Unbalanced Line Output (1 Stereo Pair, Post-Fader) 2x 1/4" TRS Stereo Headphone Output (Post-Fader) Digital I/O 1x RJ45 Ethernet Input/Output (I/O, Link) MIDI I/O No USB I/O 1x USB-C (Audio Playback, Audio Streaming, Host Connection, Recording) USB I/O Capacity 14x Input / 4 x Output Wireless Bluetooth *Built-In Mobile App Compatible No External Display I/O No Recording Max Multitrack Recording 4 Tracks Media Support SD, USB Drive Compatibility OS Compatibility macOS Windows Power DC Input Power 18 VDC at 1.5 A Physical Rack Mountable No Dimensions 10.2 x 3.3 x 8" / 25.9 x 8.4 x 20.3 cm Weight 2.6 lb / 1.2 kg
