32x16 Digital Stagebox with AES50 & ULTRANET
The
Midas MDS-DL32 is a high-capacity digital stagebox designed to expand your I/O capabilities in live sound and installation environments. Featuring 32 mic/line inputs, 16 balanced outputs, and dual AES50 SuperMAC ports, it supports seamless digital audio networking and cascading without the need for routers or mergers.
Midas MDS-DL32 Competitive Differences
- 32 balanced inputs and 16 electronically balanced low impedance outputs
- Dual AES50 ports for cascading multiple stageboxes without extra hardware
Midas MDS-DL32 Description
The
MDS-DL32 delivers exceptional audio performance and flexibility for professional sound systems. With 32 remote-controlled mic preamps and 16 balanced line-level outputs, it’s ideal for front-of-house, broadcast, or monitor applications. Built-in ULTRANET support enables personal monitoring systems and direct integration with Turbosound speakers over CAT5e.
Dual AES50 SuperMAC ports provide high-channel-count connectivity and allow easy cascading of additional stageboxes like the Midas DL16, making it scalable for larger events and complex audio setups. This plug-and-play architecture eliminates the need for mergers or routers.
Compact yet rugged, the DL32 is built for the demands of touring and installation environments, offering reliable operation and intuitive control integration with Midas and compatible digital consoles.
Model Features
- 32 mic/line inputs with remote-controlled Midas preamps
- 16 electronically balanced low impedance line outputs
- Dual AES50 SuperMAC ports for flexible cascading
- ULTRANET support for personal monitoring and speaker control
- Compact, road-ready chassis
Model Specifications
- Inputs: 32 balanced mic/line
- Outputs: 16 electronically balanced line level
- Networking: Dual AES50 ports, ULTRANET
- Dimensions: 48.3 x 24.2 x 13.8 cm
- Weight: 5.69 kg (12.54 lb)
What's In The Box
- Midas MDS-DL32 stagebox
- Power cable
- Rack mounting hardware (if included)
Midas MDS-DL32
(Midas DL32_US1)
