Proel EDGE SW121A
DISCONTINUED
This product has been discontinued by the manufacturer. Please contact us to find a replacement.
Proel EDGESW121A (Proel EDGE SW-121-A)
21in 3,000 Watt Program Power - 6,000 Watt IP Power
Amplified - NEODYMIUM woofer
Italian Made & Engineered - High Quality
processed active subwoofer
The SW121A direct-radiating 21" subwoofer completes bass response with an
impressive excursion control and amazing power handling. Its sturdy double
silicon spider (DDS) mechanical cone suspension system, the double demodulating
rings (DDR) and the over-damped enclosure provide a great deal of defined and
well controlled energy at low frequencies. A passive version is also available
(EDGE SW121P). Dedicated controls: - INFRA LPF: lowers the crossover frequency
when used as INFRASUB - MULTIPLE UNITS EQ: reduces the increase in level of the
upper low frequency range (80 Hz) due to the simultaneous use of two or more
systems - EXTENDED LOW: extends response at low frequencies
| System type | processed active subwoofer |
|---|---|
| Amplifier Continuous Power | 1500 W |
| Input Impedance | LINE: 20 kohm balanced, 10 kohm unbalanced |
| Frequency response | 32 Hz - 80 Hz (-3 dB, +6 dB) |
| Input Sensitivity | LINE: +4 dBu / 1.25 V |
| Maximum (peak) Output | 131 dB @ 1m (131 dB @ 1m) |
| Low Frequency Device | 21" neodymium woofer - 5,3" voice coil |
| Power Supply | 230 V AC 50Hz or 117 V AC 60 Hz |
| Power consumption | 510 VA (1/8 max output power) |
| Maximum Power Consumption | 2000 VA |
| Cooling | Heat sink and variable speed DC fan |
| Connectors | IN - LINK: XLR M - XLR F MAIN: PowerCon® (NAC3MPA) MAIN LINK: PowerCon® (NAC3MPB) |
| Construction | 18 mm birch plywood, internally reinforced |
| Cabinet Colour | Black |
| Mounting Pole | 1 |
| Weight | 62.5 kg (62.5 kg) |
| Dimensions (W x H x D) | 58.4 x 76.5 x 81.0 cm |
| Controls | INFRA LPF - MULTIPLE UNITS EQ - EXTENDED LOW - GND LINK |
