Moving Head Wash Light
The
Rasha K2 FX is a powerful moving head wash designed for lighting designers who need more than just color and brightness — it delivers layered visuals with precision zoom, dynamic effects, and full protocol support in a rugged, tour-ready body. From wide washes to focused beams and visual eye candy, the K2 FX adds high-performance versatility to any lighting rig.
Rasha K2 FX Competitive Differences
- RGBW LED with Aura FX panel for multi-layered effects
- Motorized zoom from 5° to 55° with infinite Pan/Tilt
Rasha K2 FX Description
The
Rasha K2 FX blends vivid RGBW output with immersive secondary effects via a built-in Aura FX panel. With 19 OSRAM 40W LEDs and 210 micro RGB LEDs, this fixture provides bold color washes and background textures in one compact form. Its 11:1 motorized zoom (5.5° to 55°) lets designers shift from tight aerial beams to smooth wide washes, making it perfect for concerts, festivals, and broadcast environments.
Engineered with infinite Pan and Tilt rotation, the K2 FX allows seamless, sweeping motion across the stage, while its flicker-free PWM options (up to 25kHz) make it camera-ready for video shoots and streaming. The fixture’s NFC-enabled LCD interface allows quick address setup, even without powering on the unit, ideal for fast-paced production workflows.
Every K2 FX supports Art-Net, sACN, RDM, DMX, and wireless protocols (CRMX and W-DMX) through its onboard LumenRadio TiMo FX module. The fan-controlled cooling system offers multiple modes for balancing noise and performance. Housed in high-impact thermoplastic with locking pan/tilt and Omega bracket rigging points, the K2 FX is built to last in touring and rental environments.
Model Features
- RGBW moving head wash with built-in Aura FX panel
- 19x OSRAM 40W RGBW LEDs + 210 RGB micro LEDs
- Motorized zoom: 5.5° to 55°
- Infinite Pan/Tilt rotation with manual locks
- NFC-enabled full-color LCD menu with reversible display
- Supports DMX, RDM, Art-Net, sACN, CRMX, and W-DMX
- Selectable flicker-free PWM (up to 25kHz)
- Built-in receiver/transmitter modes for wireless control
Model Specifications
- Dimensions: 15.79 × 9.72 × 20.59 in (401 × 247 × 523 mm)
- Weight: 42.3 lb (19.2 kg)
- Zoom Range: 5.5° to 55° (11:1 ratio)
- Lumens (Source): 4500 lm
- Color Temp Range: 2,000K–10,000K
- Illuminance: 42,400 Lux (narrow) / 1,120 Lux (wide) @ 5m
- Input Voltage: 110–240V AC, 50/60 Hz (Auto-ranging)
- Power Consumption: 788W
- Control Protocols: DMX, Art-Net, sACN, RDM, CRMX, W-DMX
- DMX Modes: 36Ch, 49Ch, 125Ch
- Cooling: Active temperature-controlled fan
- IP Rating: IP20
- Noise Level: 50 dB(A) @ 1m
What's In The Box
- Rasha K2 FX Moving Head Fixture
- Powercon cable
- Omega mounting brackets
- User manual
RASHA K2 FX
(Rasha RP-K2FX-BLK)
