High-Output 12" Active Point-Source Speaker with RDNet and BMC
The
RCF KX 32-A is a compact, high-performance 2-way active speaker designed for professional touring, rental, and install applications. Featuring a 12" neodymium woofer, titanium dome compression driver, and a 3200W Class-D amplifier, it delivers up to 134 dB SPL with pinpoint precision. Integrated DSP with FiRPHASE and Bass Motion Control (BMC) ensures linear, distortion-free output, while RDNet and rotatable horn support versatile deployment in any venue.
RCF KX 32-A Competitive Differences
- 3200W peak two-channel Class-D amplifier for powerful sound delivery
- 12" neodymium woofer with 3.5" voice coil for deep, controlled low end
- 3" titanium dome neodymium compression driver for clear HF
- Rotatable 100° x 70° True Resistive Waveguide for flexible coverage
- Integrated RDNet for real-time system monitoring and remote tuning
- Bass Motion Control (BMC) DSP technology for enhanced low-frequency linearity
- FiRPHASE filtering ensures coherent phase and amplitude response
- Weather-resistant Baltic birch enclosure with durable Polyurea coating
- Quick lock rigging, pole mount, and multiple M10 suspension points
RCF KX 32-A Description
The
RCF KX 32-A is engineered for versatility, offering high SPL output, wide coverage, and networked DSP control in a compact enclosure. Its 12” neodymium woofer and 3” compression driver are powered by a 3200W Class-D amplifier, delivering up to 134 dB SPL across a wide 50 Hz – 20 kHz frequency response. With a low crossover point of 750 Hz, the system maintains outstanding midrange clarity and transient response.
The advanced DSP engine incorporates RCF's FiRPHASE and BMC (Bass Motion Control) technologies for unmatched accuracy, phase coherence, and low-frequency performance without over-excursion. RDNet compatibility provides full system control—including presets, gain, limiter status, and environmental tuning—making it ideal for complex touring or install environments.
Constructed from high-grade Baltic birch plywood with a Polyurea finish, the KX 32-A is ready for the road. Quick lock hardware, M10 rigging points, and PowerCON TRUE1 TOP connectors support flexible mounting and safe operation under any condition. Whether used for FOH, side fill, or flown configurations, the KX 32-A offers uncompromising performance in a road-tough package.
KX 32-A Features
- 3200W peak power (2000W LF / 1200W HF)
- Maximum SPL: 134 dB
- 12” neodymium woofer with 3.5” voice coil
- 1.4” titanium dome compression driver with 3” voice coil
- Rotatable 100° x 70° True Resistive Waveguide horn
- Onboard RDNet for advanced DSP control and monitoring
- FiRPHASE filters for linear phase response
- Bass Motion Control (BMC) for extended low-end performance
- Polyurea-coated Baltic birch cabinet with reinforced internal structure
- PowerCON TRUE1 TOP in/out connectors
- Quick lock rigging points and multiple M10 mounting options
KX 32-A Specifications
- Frequency Response: 50 Hz – 20,000 Hz
- Max SPL: 134 dB
- Horizontal Coverage: 100°
- Vertical Coverage: 70°
- Amplifier Power: 3200W Peak
- HF Power: 1200W Peak
- LF Power: 2000W Peak
- Compression Driver: 1.4" neodymium, 3.0" voice coil
- Woofer: 12" neodymium, 3.5" voice coil
- Crossover Frequency: 750 Hz
- Input Sensitivity: -2 dBu / +4 dBu
- Input Connectors: XLR, RDNet Ethercon
- Output Connectors: XLR, RDNet Ethercon
- Cooling: Convection
- Protections: Thermal, HF, fast limiter
- Controls: Gain reduction, 8 user-selectable presets
- Power Connections: PowerCON TRUE1 TOP In/Out
- Cabinet Material: Baltic birch plywood with Polyurea finish
- Hardware: Quick lock pins, 3 × M10 top and bottom, 35 mm pole mount
- Handles: 2 side-mounted with rubber grips
- Grille: Steel with protective cloth
- Color: Black
- Dimensions (H × W × D): 24.41 × 14.17 × 16.11 in (620 × 360 × 409.3 mm)
- Shipping Dimensions (H × W × D): 28.19 × 16.1 × 18.03 in (716 × 409 × 458 mm)
- Shipping Weight: 56.99 lbs (25.85 kg)
rcf KX 32-A
(RCF 13000903)
