High-Output 2-Way Active Speaker for Precise Coverage
The
RCF KXW 4-A delivers exceptional sound performance with high SPL output, wide horizontal coverage, and precise vertical dispersion. Engineered for professional live sound and installations, it features dual 10" neodymium woofers and a large-format 4” compression driver, powered by a 3200W Class-D amplifier. Whether ground-stacked, flown, or pole-mounted, this compact and weather-resistant enclosure is ideal for demanding touring and installation applications.
RCF KXW 4-A Competitive Differences
- 134 dB maximum SPL with compact cabinet design
- Rotatable 100° x 50° horn for adaptable coverage
- Dual 10” neodymium woofers with 3” voice coils
- 4” titanium dome compression driver with 1.4” exit
- Onboard RDNet for remote control, monitoring, and preset recall
- FiRPHASE and Bass Motion Control DSP processing
- PowerCON TRUE1 TOP in/out connectors for rugged reliability
- Durable weather-resistant Baltic birch cabinet with array rigging options
RCF KXW 4-A Description
The
KXW 4-A combines flexibility and power in a compact form factor, perfect for pro audio setups that demand accuracy and SPL without bulk. The rotatable 100° x 50° horn enables use in vertical or horizontal orientation, offering precise coverage for front-fills, main FOH, or distributed systems. The onboard RDNet-ready DSP provides extensive control, while built-in thermal and RMS protection ensures long-term reliability in the harshest conditions.
Its high-output 3200W peak amplifier is split between 2000W LF and 1200W HF sections. With an optimized crossover at 900 Hz and support for multiple DSP presets, this loudspeaker adapts seamlessly to different environments and configurations.
KXW 4-A Features
- 134 dB maximum SPL
- Rotatable 100° x 50° horn
- 2 x 10" neodymium woofers with 3” voice coils
- 1 x 4” titanium dome compression driver with 1.4” exit
- 3200W peak power (2000W LF + 1200W HF)
- Onboard DSP with FiRPHASE and Bass Motion Control
- 8 user-selectable DSP presets with RDNet remote control
- Fast limiter, thermal, and RMS protection circuitry
- Balanced XLR + RDNet Ethercon input and output
- PowerCON TRUE1 TOP power input/output
KXW 4-A Specifications
- Frequency Response: 45 Hz – 20,000 Hz
- Max SPL @ 1m: 134 dB
- Coverage: 100° horizontal x 50° vertical
- Crossover Frequency: 900 Hz
- Input Sensitivity: +4 dBu
- Protections: Thermal, RMS, Fast Limiter
KXW 4-A Physical Specifications
- Cabinet Material: Baltic birch plywood
- Grille: Steel with acoustic fabric backing
- Handles: 2 side, 2 rear
- Mounting: 35 mm pole socket, array fittings, M10/M8 rigging points
- Color: Black
KXW 4-A Dimensions & Weight
- Height: 32.48 in (825 mm)
- Width: 12.2 in (310 mm)
- Depth: 14.53 in (369 mm)
- Weight: 67.02 lbs (30.4 kg)
Shipping Dimensions
- Height: 16.14 in (410 mm)
- Width: 34.06 in (865 mm)
- Depth: 14.37 in (365 mm)
- Shipping Weight: 73.85 lbs (33.5 kg)
RCF KXW 4-A
(RCF 13000884)
