The SUB 8003-AS II active subwoofer features the latest generation of RCF woofer technology, digital amplifiers and DSP processing with higher power and enhanced performance. It offers the perfect blend of bass reproduction, high SPL and compact dimensions for mobile use by bands and DJs.
FEATURES
• 2200 W
• 135 dB max SPL
• 35 Hz - 120 Hz frequency response
• 18" Woofer, 4.0" v.c.
• Selectable gain, X-over and delay
• Birch tour grade cabinet
• Stereo XLR input, Stereo XLR signal output
TECHNICAL SPECIFICATIONS
Acoustical specifications Frequency Response: 35 Hz ÷ 120 Hz
Max SPL @ 1m: 135 dB
Transducers Woofer: 18'', 4.0'' v.c
Input/Output section Input signal: bal/unbal
Input connectors: XLR
Output connectors: XLR
Input sensitivity: -2 dBu/+4 dBu
Processor section Crossover Frequencies: Selectable
Protections: Thermal, RMS
Controls: Gain, EQ, Phase, Xover, Delay, Cardioid
Power section Total Power: 2200 W Peak, 1100 W RMS
Low frequencies: 2200 W Peak, 1100 W RMS
Cooling: Convection
Connections: Powercon IN/OUT
Standard compliance CE marking: Yes
Physical specifications Cabinet/Case Material: Baltic birch plywood
Handles: 2 side
Pole mount/Cap: Yes
Grille: Steel
Color: Black
Size Height: 694 mm / 27.32 inches
Width: 523 mm / 20.59 inches
Depth: 700 mm / 27.56 inches
Weight: 45 kg / 99.21 lbs
Shipping informations Package Height: 745 mm / 29.33 inches
Package Width: 760 mm / 29.92 inches
Package Depth: 580 mm / 22.83 inches
Package Weight: 51 kg / 112.44 lbs
RCF sub8003 mk2
(RCF sub 8003 as mk2)
