Smoke Factory SF-39133

Interface PCB with Multi‑Connector Panel for Fog/Haze Machines

Smoke Factory SF-39133 is a replacement interface board designed to provide the multi‑connector panel I/O (2 × 5‑pin XLR, 1 × 3‑pin XLR, plus 1 × Ethernet port) for compatible Smoke Factory machines. It handles signal routing for DMX, remote control, data communication, and external control inputs/outputs.

Smoke Factory SF-39133 Competitive Differences

• Supports multiple standard connections — 5‑pin XLR (commonly DMX), 3‑pin XLR (analog or remote), and Ethernet (for network/control protocols)
• Offers a clean, factory‑compatible solution for replacing damaged or worn connector interface boards — preserving the original wiring harness layout and machine functionality

Smoke Factory SF-39133 Description

In many of Smoke Factory’s higher‑end fog and haze machines, external control and integration require multiple connectors — e.g. 5‑pin XLR for DMX 512, 3‑pin XLR for analog remote or cable remote control, and Ethernet for networked control protocols or units equipped with digital interface options. SF‑39133 consolidates these inputs and outputs on a single PCB assembly. If the original connectors or interface board becomes damaged — for example, due to wear, impact, moisture ingress, or repeated cable insertions — replacing it with SF‑39133 restores the machine’s full external control capabilities. This is especially important for professional rigs, rental houses, or touring setups where reliability and compatibility with standard control protocols (DMX, remote, digital) are essential. Because this is a dedicated replacement PCB, it should match the mounting points, wiring harness connectors, and signal routing of the original unit — minimizing compatibility issues and avoiding custom rewiring.

Model Features

• Multi‑connector I/O board for Smoke Factory machines: 2 × 5‑pin XLR, 1 × 3‑pin XLR, and 1 × Ethernet port
• Supports standard control interfaces: DMX 512, analog remote, cable remote, and Ethernet‑based protocols (if supported by the machine)
• Replacement‑ready — designed to drop into original mounting bracket and use existing harness/connectors
• Restores full external connectivity — ideal for machines with damaged panels or worn-out connectors

Model Specifications

• Part Number: SF‑39133
• Connectors: 2 × 5‑pin XLR, 1 × 3‑pin XLR, 1 × Ethernet (RJ‑45 or equivalent)
• Purpose: External control interface board / connector panel assembly
• Compatible With: Smoke Factory fog/haze machines that originally shipped with multi‑connector I/O (including DMX and remote/Ethernet control support) — confirm machine model before ordering

What’s In The Box

*(typical delivery set)*

• Interface PCB assembly (SF‑39133)
• Connector panel with mounted XLR and Ethernet ports
• Mounting hardware (screws/brackets) for original housing — assuming standard mounting pattern
