Compact Passive Line Array Speaker for Live Sound and Installations
The
Studiomaster V6 is a high-output, compact
passive line array speaker engineered for demanding touring, rental, and fixed installation environments. Featuring
dual 6.5" MF drivers with 38mm voice coils and a powerful
3" voice coil neodymium HF driver, the V6 delivers impressive clarity and output—up to
132 dB SPL—in a rugged, lightweight enclosure.
Studiomaster V6 Competitive Differences
- 132 dB Max SPL: Concert-level performance in a compact array module
- Dual 6.5" Mid-Frequency Drivers: 38mm voice coils for responsive midrange
- 3" Neodymium HF Driver: Lightweight and powerful for crystal-clear highs
- Reinforced PP Composite Cabinet: Rugged, weather-resistant and lightweight
- 100° x 10° Dispersion: Controlled coverage for scalable arrays
- Integrated Vertical Splay Mechanism: 0–10° angle adjustments in 1° steps
- Easy Array Integration: Ideal for use with matching V6SA LF modules
Studiomaster V6 Description
The
Studiomaster V6 is a 2-way
passive line array speaker that brings touring-grade clarity and SPL performance to compact installations and mobile systems. With a rugged
polypropylene composite cabinet and a tight 100° x 10° dispersion pattern, it’s ideal for tightly packed venues, outdoor stages, and scalable PA arrays.
Inside, two
6.5" mid-frequency drivers and a
3" neodymium compression driver deliver clean, dynamic output with minimal distortion. The V6 integrates seamlessly with Studiomaster’s matching subs and amplifiers, while its vertical splay design allows precise angling—up to 10°—for tailored sound coverage in line array deployments.
This speaker’s lightweight build and robust hardware make it a go-to for professionals who need durable, high-output speakers in a flexible format that works in both mobile and installed systems.
V6 Features
- Passive 2-way line array speaker
- Max SPL: 132 dB
- Frequency response: 70 Hz – 20 kHz (-10 dB)
- 100° x 10° (H x V) coverage
- Dual 6.5" MF drivers with 38mm voice coils
- 1 x 3" voice coil neodymium HF compression driver
- Reinforced composite polypropylene enclosure
- Vertical splay angle: 0–10° (1° increments)
- Lightweight at only 28.6 lbs (13 kg)
V6 Specifications
- Maximum SPL: 132 dB
- Amplifier Power (for reference with active model): MF 400W / HF 150W
- Frequency Response: 70 Hz – 20,000 Hz (-10 dB)
- Coverage: 100° horizontal × 10° vertical
- Sensitivity (1W@1m): 100 dB
- Impedance: 16 ohms
- MF Drivers: 2 x 6.5" with 38mm voice coils
- HF Driver: 1 x 3" neodymium compression driver with 74mm voice coil
- DSP: Not included (external processing required)
- Crossover Frequency: Not specified (external crossover recommended)
- Vertical Splay Angle: Adjustable from 0° to 10° in 1° increments
- Cabinet Material: Reinforced composite PP
- Dimensions (W x H x D): 18.5" x 8.15" x 13.43" (470 x 207 x 341 mm)
- Weight: 28.6 lbs (13 kg)
