Yamaha CXR15 MK3 | 15in Passive Loudspeaker - 126d...
$799.99
Yamaha CXR15 MK3 is a 2-way passive loudspeaker built for professional sound reinforcement, stage use, and fixed installation applications. As the largest full-range model in the CXR mk3 series, it combines strong output, extended low-frequency performance, and flexible deployment options for users who need a dependable passive speaker for demanding audio environments.
The Yamaha CXR15 MK3 is designed for users who want a passive full-range loudspeaker with more low-end authority than smaller cabinet sizes can provide. Its 15-inch low-frequency driver and 1.75-inch high-frequency compression driver are housed in a 2-way bass-reflex enclosure that makes it well suited for mobile DJs, live bands, event production, houses of worship, and venues that need strong, clear full-range reinforcement.
Yamaha equips the CXR15 MK3 with proprietary high-durability LF and HF drivers engineered for reliable performance and precise sound reproduction. A large-diameter horn helps maintain directivity control across a wide frequency range, while optimized port positioning reduces standing wave effects for smoother and more accurate low-frequency response. This gives the speaker a balanced sound with added low-end weight for main PA use.
The lightweight polypropylene enclosure is built for practical handling and flexible placement in both portable and installed systems. Its symmetrical cabinet supports consistent monitor placement, while dual-angle pole sockets allow either a 0-degree or -7-degree down tilt for improved audience coverage. Integrated rigging points and support for the optional UB-DXR15A U-bracket also make the speaker suitable for suspended or mounted installation.
When paired with compatible Yamaha PX and PC-D Series amplifiers or other supported signal processors, the Yamaha CXR15 MK3 can take advantage of dedicated speaker processor tuning settings for optimized system performance. This makes it a strong option for users building a passive Yamaha sound system with matched processing and amplification.
| Beam Angle | 90° H x 60° V degrees |
| Frequency Response | 50 Hz - 20 kHz Hz |
| Impedance | 8 Ω Ω |
| LED Type | 15 inch cone inch |
| Lumen Output | 126 dB SPL dB SPL |
| Power Rating | 1200W W |
| Wattage | 1200W peak W |
| Brand | Yamaha |
| Name | Yamaha CXR15 MK3 |
| Primary Category | Passive Loudspeaker |
| Build Material | Plastic (Polypropylene) |
| Dimensions | 17.6 x 27.5 x 15.0 in (447 x 699 x 380 mm) mm |
| Included Accessories | None included; optional UB-DXR15A U-bracket and SPCVR-DXR153 cover available |
| Mounting Options | Dual-angle pole sockets (0° or -7° tilt), rigging points for eyebolts, compatible with UB-DXR15A U-bracket |
| Weight | 41.9 lb (19.0 kg) kg |
| Control Interfaces | SpeakON NL4MP x2 (parallel connected) |
