22-Channel Digital Mixing Console
The
Yamaha MGX16 W is a flexible and powerful 22-channel digital mixer that combines high-end performance with an intuitive interface. Designed for live sound, podcasting, streaming, and studio production, it brings together advanced routing, customizable FX, and Bluetooth connectivity—all in a portable, rugged chassis with a modern white finish.
Yamaha MGX16 W Competitive Differences
- Dual USB ports: 22x18 recording/playback + 2x2 secondary interface
- Customizable sound pads and scene recall for creative flexibility
Yamaha MGX16 W Description
The
Yamaha MGX16 W takes the legacy of Yamaha’s MG analog mixers into the digital realm—offering a hands-on mixing experience tailored for hybrid workflows. Its 4.3” touchscreen GUI, motorized faders, and customizable user-defined controls make it easy to shape your sound, route signals, and recall presets across a variety of environments.
Whether you’re producing a livestream, recording a band, managing sound for an event, or setting up for a podcast, the MGX16 W adapts to your workflow with ease. Dual USB-C ports support both multitrack and two-track recording/playback. Bluetooth audio input, built-in DSP, and microSD card support give you creative freedom and fail-safe recording options on the go.
Despite its pro-level specs, the MGX16 W remains lightweight and compact—perfect for gigging musicians, mobile engineers, and fixed installations alike.
Model Features
- 22-channel mixing with 8 mono and 4 stereo channels
- Built-in studio-quality FX: EQ, Compression, Gate, Reverb, Delay, Amp Sim
- Smart Gain and Clip Safe prevent distortion and simplify setup
- Touchscreen GUI with TOUCH AND TURN encoder and 16 motorized faders
- Scene memory and customizable pads for fast workflow switching
Model Specifications
- Max I/O: 16x Input / 14x Output
- Power Output: USB Main 22-in / 18-out, USB Sub 2-in / 2-out
- Analog Inputs: 8x Combo XLR-1/4", 4x 1/4" TRS, 2x RCA
- Analog Outputs: 2x XLR, 8x 1/4" Bus, 4x 1/4" Headphone
- Max SPL: Not specified
- Frequency Response: 20 Hz to 20 kHz (+1/-2 dB)
- Dynamic Range: 125 dB (output), 115 dB (input to output)
- USB: 2x USB-C ports (multitrack and playback/control)
- Wireless: Bluetooth 5.0 (built-in)
- Recording: 18-track USB, 16-track microSD (WAV/MP3)
- Dimensions: 16.5 x 3.8 x 12.5 in (419.1 x 96.5 x 317.5 mm)
- Weight: 10.4 lb (4.7 kg)
What's In The Box
- Yamaha MGX16 W Digital Mixer (White)
- Power Cable
- Steinberg Software License Card (Cubase AI, WaveLab Cast LE, FX Suite)
Yamaha MGX16 W
(Yamaha MGX16-W)
