Ape Labs NeonStripe 8

Innovative, Flexible, and Seamless LED Lighting for Indoor and Outdoor Applications

The Ape Labs NeonStripe is a versatile RGBaW LED strip with cutting-edge COB (Chip On Board) technology, offering fully homogeneous lighting without visible LEDs. This strip is designed for professional indoor and outdoor installations, with an IP65 rating ensuring protection from water and dust. Its flexibility, cuttable design, and plug-and-play connectivity make it an excellent solution for creating dynamic lighting in a variety of environments, such as events, TV, film, architectural lighting, and more.

Each NeonStripe comes with IP65-rated pigtail connectors on both sides, allowing for quick and easy installations without soldering. The strip can be customized to fit specific installation needs, and included mounting clips and hardware make the setup process seamless. An Ape Labs NeonStripe Box is required to power and control the NeonStripe LEDs, but each box can power up to 65.6ft (20 meters) of LED linear length, providing even more flexibility for large-scale projects.

Ape Labs NeonStripe Features

• COB Technology: Offers fully homogeneous illumination with no visible LEDs for a smooth lighting effect.
• RGBaW LED: Provides vibrant, rich colors and a high CRI of 90 for excellent color rendering.
• Cuttable Design: Customize the strip to fit your specific installation needs.
• IP65 Rating: Weatherproof and dustproof, suitable for outdoor installations.
• 5-Pin Pigtail IP Connectors: Easy plug-and-play installation with male/female connectors and end caps on both sides.
• Mounting Hardware Included: Comes with clips and installation hardware for quick setup.
• Wireless Control: Compatible with ApeRemote, the Ape Labs Connect app, and wireless DMX control options.
• Loop-Capable: Supports up to 65.6ft (20 meters) of connected NeonStripes when paired with a NeonStripe Box.
• High Efficiency: 24V, 5W per meter for energy-efficient operation.

Specifications

• LED Chipset: COB RGBaW
• CRI: 90
• Color Temperature: 2700K (Warm White)
• Voltage: 24V
• Power Consumption: 5W per meter
• IP Rating: IP65 (waterproof and dustproof)
• Connectors: 5-pin pigtail IP connectors, male/female with end caps
• Loop Capability: Up to 65.6ft (20 meters) per NeonStripe Box
• Included Accessories: Mounting clips and installation hardware

Available Lengths

• NeonStripe 2: 1.64ft (0.5 meters)
• NeonStripe 3: 3.28ft (1 meter)
• NeonStripe 8: 8.2ft (2.5 meters)
• NeonStripe 16: 16.4ft (5 meters)
• NeonStripe Extension 5: 4.92ft cable extension (without LEDs)

Ape Labs Ecosystem

• Grouping: Super Easy & Flexible Control
• MusikMode: 1-Button Light Show
• 1-Mile Wireless Range w/ App & DMX
• 200ft Wireless Range w/ RF Remote
• Up to 48hr Battery Life w/ Power-Save Mode
• Wireless Range Increases as More Fixtures are Added

• Color Macros Mixed By USA Event Industry Leaders
• RGBaW LEDs w/ Super High Efficiency
• Flicker Free Mode for Video Recording
• High CRI Output, Ultra Vivid Colors

• Automatic Integration & Syncing w/ Every SKU
• On-The-Fly Programming, Remote Addressing, Smart Sync
• Cross-Platform and Community Sharing of Programs

• Solid State, Fanless Operation
• Free Firmware Updates for Life
• Compact and Lightweight
• Premium Components for Superior Quality
• 100% Designed, Engineered & Hand Assembled in Germany
• 3-Year USA Warranty

Accessories (not included, but required for use)

• NeonStripe Box: Plug-and-play controller with built-in 100W Meanwell power supply, IP65 rated, compatible with ApeRemote, wireless DMX, and the Ape Labs Connect app. At least one ApeRemote or Connect is also a required accessory for any Ape Labs application.
• (Optional) NeonStripe Extension 5: If needed, jump between NeonStripe Box and NeonStripe, or between multiple NeonStripes

Apelabs Neon Stripe 2.5 (8.2ft) (Ape Labs Neon LED Strip Tape 8)
