COLORado 1QS is a robust indoor/outdoor wash light that delivers fully homogenized output from a single, high-power RGBW LED source. A 17° beam angle offers versatile control and 16 bit-dimming facilitates smooth fades. The unit’s IP65 housing makes it ideal for touring, rental, and production markets. Outdoor-rated power and data connectors allow for easy connections without propriety cabling. The unit also includes an omega bracket with ¼ turn adaptors for fast and easy rigging and is compatible with all 7.5” accessories.
Features:
RGBW LED wash for touring, rental, and production, indoors or out
All environment operation with IP rated power and DMX connections
Flat, even field of light from a single source
RDM and variable PWM (Pulse Width Modulation) for setup ease
Accepts standard 7.5” beam shaping accessories
16-bit dimming resolution for smooth fades
Double-bracket yoke doubles as floor stand
Specifications:
OPTICAL
Light Source: 24 LEDs (quad-color RGBW) 3 W, (900 mA), 50,000 hours life expectancy.
Color Temperature (range): 2800 to 10,000 K
Beam Angle: 17°
Field Angle: 30°
Lumens: 3401 lm
Illuminance (total): 1268 lux @ 5 m
Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 2400 Hz, 6000 Hz, 18,000 Hz, 25,000 Hz
DYNAMIC EFFECTS
Dimmer: Electronic
Shutter/Strobe: Electronic
Strobe Rate: 0 to 20 Hz
Standalone Color Mixing: Yes
Color Temperature Presets: No
Dim Modes: 5
Built-in Automated Programs: Yes
Customizable Programs: Yes
Recall Custom Programs: Yes
CONNECTIONS
Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
Power Input: Seetronic Powerkon IP65
Power Output: Seetronic Powerkon IP65
Data Connectors: 5-pin XLR
Cable Length (power): 5 ft (1.5 m)
CONTROL
Control Protocol: DMX, RDM
DMX Channels: 7, 10 or 15
Modes/Personalities: 5 personalities (HSIC, SSP, TOUR, TR16, STD.Y)
ELECTRICAL
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 18 @ units 100 V; 22 units @ 120 V; 35 units @ 208 V; 38 units @ 230 V; 40 units @ 240 V
Power and Current: 74 W, 0.613 A @ 120 V, 60 Hz
Power and Current: 79 W, 0.385 A @ 208 V, 60 Hz
Power and Current: 80 W, 0.350 A @ 230 V, 50 Hz
CONSTRUCTION / PHYSICAL
Dimensions: 10.75 x 8.27 x 13.19 in (273 x 210 x 335 mm)
Weight: 10.8 lb (5.0 kg)
Exterior Color: Black
Housing Material: Aluminum die-cast
Accessory Holder/Gel Frame Size: 7.5 in (191 mm)
CERTIFICATIONS / QUALIFICATIONS
CE, MET
IP Rating: IP65, outdoor/wet, with pressure equalizing M12 GORE valve
WHAT'S INCLUDED
COLORado 1QS
Seetronic Powerkon IP65 power cord
Gel Frame
Omega Bracket
OPTIONAL ACCESSORIES
Professional Clamps: CTC-50HC, CTC-50HCN
Neutrik® powerCON® cables
3-pin or 5-pin DMX Cables
Color Blending Filters: DF60X1D, DF20D
Ovation F7.5” Barn door
Ovation 60 deg, 7.5” Honeycomb
