Powerful Class D Amplification
The XPRS2 Series employs Class D Amplification with high output wattage for a powerful and premiere audio experience for performers and listeners alike. The XPRS102 and XPRS122 full-range speakers feature Class D 2000 W amplification, while the XPRS1152S and XPRS1182S subwoofers offer Class D 4000 W amplification.
xprs2 series key feature 2
High Quality, Robust Build
Pioneer DJ’s all-new XPRS2 Series features a sleek all-black, protective pollywood cabinet for performance in harsh outdoor and indoor environments. The series models all come with a durable handle to support system portability and handling during setup and take down. The XPRS2 Series also features rubber feet to create separation and shock absorption between surfaces.
xprs2 series key feature 3
Four DSP Modes
Both of the XPRS2 full-range speakers contain four different DSP preset modes—Live, Music, Speech and Studio Monitoring—to address the needs of different listening environments.
xprs2 series key feature 9
16 Customizable User DSP Modes
In addition to the four presets, each XPRS2 full-range speaker includes 16 custom user DSP modes - which can be saved with different names - to ensure the EQ settings are maximized for every scenario.
xprs2 series key feature 4
Full-Range Speaker Design
The XPRS102 pairs a 10” woofer and 2.5” voice coil with a 1” exit compression driver and 1.75” voice coil to deliver pristine audio performance. Complete with a maximum sound pressure level (SPL) of 129 dB and frequency response of 50 Hz–20 kHz, the XPRS102 full range speakers help ensure music and spoken word reproduction is accurate and performs as intended.
FEATURES:
Type
10 inch 2-way active loudspeaker
Amplifier Output
Class D
2000W peak
What's in the box
XPRS102 x 1 (not sold as a pair)
Powerd cord
Quick start guide
Important Safety Precautions
SPECIFICATIONS:
Supported voltages
110 V to 240 V (50 Hz/60 Hz)
Power consumption
800 W
Frequency Range
50 - 20000 Hz
Width
11.77 in
Height
20.47 in
Depth
12.2 in
Weight
34.17 lb
System characteristic
DSP modes
Factory Presets (4 types)
Sub Setting (Sub Setting menu is for selecting the high-pass frequency or matching subwoofer)
EQ (4-band equalizer)
User Programs (16 presets)
DSP presets modes
Factory presets
LIVE
MUSIC
SPEECH
MONITOR
Maximum Sound Pressure
129 dB
Cross Over Frequency
2 kHz
Terminals
Inputs
MIC / LINE x 1 (Combo)
HI-Z / LINE x 1 (Combo)
3.5 mm stereo mini jack x 1 (Unbalanced input)
Outputs
MIX (XLR)
Speaker
Driver
10 inch ferrite LF cone driver
1.75 inch compression driver
Finish
Black paint, Rubber feet
Handle
1 metal handle (on left side)
Pole socket
35 mm socket
Rigging point
10x M10
Enclosure
Plywood (TSCA)
Protection
Amplifier Protection
Thermal limiting
Digital Limiter
Digital compressor
Driver Protection
Short circuit protection
Power unit Protection
Primary AC mains overcurrent protection
Primary AC mains overvoltage protection
Pioneer Dj XPRS 102
(Pioneer DJ XPRS-102)
