The ILS (Integrated Lighting System) universe grows with the addition of this powerful full-size quad-colored (RGBA) linear wash light with built-in Bluetooth® wireless technology. Bluetooth® and ILS compatibility means almost unlimited convenience when it comes to control options. Of course, onboard Bluetooth® technology means you can control the unit directly from a smart phone or tablet without any additional hardware. But that’s not all. COLORband Q3BT ILS also features D-Fi USB compatibility for wireless master/slave or DMX control. 3 zones of control let you create amazing, automated effects. Fits best in the CHS-60 VIP Gear Bag.
FEATURES:
Full-size linear wash light with built-in Bluetooth® wireless technology
ILS compatibility for use in the ILS ecosystem
D-Fi USB compatibility for wireless master/slave or DMX control
Control directly from a smart phone or tablet without any additional hardware
3 zones of control create amazing, automated effects
Easily set static colors or automated programs with the optional IRC-6 remote
Save time running cables and extension cords by power linking multiple units
Fits best in the CHS-60 VIP Gear Bag
SPECIFICATIONS:
DMX Channels: 4, 6 or 16
DMX Connectors: 3-pin XLR
Light Source: 12 LEDs (quad-color RGBA), 4 W (1 A) 50,000 hours life expectancy
Strobe Rate: 0 to 20 Hz
Beam Angle: 50°
Operating Frequency: 2.4GHz
Coverage Angle: 108°
Illuminance: 509 lux @ 2 m
Power Linking: 10 units @ 120 V; 19 units @ 230 V
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current:
54 W, 0.8 A @ 120 V, 60 Hz
52 W, 0.4 A @ 230 V, 50 Hz
Weight: 6.6 lb (3 kg)
Size: 39.3 x 3.8 x 5.5 in (1000 x 98 x 140 mm)
Approvals: CE, RoHS, UKCA, FCC
Optional Controllers: IRC-6
Bluetooth version: 4.2
Max Unobstructed Distance: 150 ft (45.7 m)
WHAT'S INCLUDED
COLORband Q3BT ILS
Power cord
Quick Reference Guide
