ETC CSSPOTJR2550-A

Zoomable LED stage spotlight for theater, houses of worship, and live venues

The ETC CSSPOTJR2550-A ColorSource Spot jr delivers high-quality color mixing, quiet performance, and flexible beam shaping—all in a compact and affordable form factor. Designed with a 25°–50° zoom range and an Edison power connector, this fixture is ideal for small to mid-sized venues seeking professional-grade lighting without the high price tag.

ETC CSSPOTJR2550-A Competitive Differences

• 25°–50° built-in zoom with sharp shutter cuts and adjustable beam edges
• 5,700 lumens of brightness in a lightweight, compact body
• Includes 1.5m powerCON input cable with Edison plug
• Factory-calibrated four-color (RGBL) LED array ensures consistent output
• Advanced thermal management for reliable, long-term use
• Exceptional 5-year fixture warranty and 10-year LED array warranty
• Stand-alone operation with built-in presets and sequences
• RDM and DMX512-A compliant with real-time temperature monitoring

ETC CSSPOTJR2550-A Description

The ETC CSSPOTJR2550-A ColorSource Spot jr is a versatile LED spotlight that brings ETC’s industry-leading color technology into a more compact and accessible design. With a zoom range of 25° to 50°, it’s ideal for applications requiring flexibility in beam size—from spotlighting a performer to texturing a background with a gobo.

This fixture utilizes a four-color mixing system (Red, Green, Blue, Lime) to deliver rich, vibrant colors and subtle pastels. Factory calibration ensures consistent color across units, regardless of production batch. Featuring droop compensation and high-resolution 15-bit dimming, the fixture delivers smooth fades and flicker-free operation, even in broadcast environments.

The CSSPOTJR2550-A is built to last with an L70 rating of 50,000+ hours, supported by LM-80 test data. It’s designed with rugged ABS housing, stainless steel shutters, and a durable steel yoke. The 1.5m powerCON power input cable with Edison plug ensures plug-and-play compatibility in a variety of settings.

Built-in stand-alone functionality, including 12 preset colors and 5 sequences, makes it ideal for installations without a lighting console. With RDM control, DMX In/Thru, and easy menu navigation via a 7-segment display, this fixture is as user-friendly as it is powerful.

CSSPOTJR2550-A Features

• 25°–50° zoom range with high-quality optical system
• Four-color RGBL mixing with factory calibration
• 5,700-lumen output in a lightweight housing
• 1.5m powerCON input cable with Edison connector
• High-speed PWM dimming (up to 25,000Hz via RDM)
• 15-bit dimming with incandescent curve for smooth fades
• 0.024" stainless steel shutters with three-plane shutter system
• Variable-rate strobe channel
• Stand-alone functionality with presets and sequences
• 7-segment display with 3-button user interface
• 300°+ rotation via rugged steel yoke with dual mounting positions

CSSPOTJR2550-A Specifications

• Output: 5,700 lumens
• Zoom Range: 25° to 50°
• LED Type: Red, Green, Blue, Lime (minimum 52 emitters)
• L70 Rating: 50,000+ hours
• Power Input: 1.5m powerCON cable with Edison plug
• DMX: USITT DMX512-A with 5-pin XLR In/Thru
• RDM: ANSI E1.20 compatible with full function access
• Cooling: Integrated active cooling with fan
• Construction: ABS plastic housing, stainless steel shutters
• Mounting: Dual-position steel yoke with 300°+ rotation
• Rated for dry location use (IP20)
• Certifications: UL1598, ETL, cETL, CE
• Warranty: 5 years fixture, 10 years LED array

E T C 7416A1001-A (ETC CSSPOTJR2550 w/ Edison Connector)
