Versatile Compact Loudspeaker for Distributed Audio Systems
The
CSS-1S/T is a compact and versatile two-way loudspeaker designed for both distributed 100V/70V speaker lines and 8 ohm direct mode applications. It features a 5.25-inch low-frequency driver and a 0.75-inch polycarbonate dome tweeter, providing high-quality sound reproduction for both music and speech. The speaker is designed to be purchased in pairs, ensuring balanced sound coverage for commercial or residential settings. An included wall-mounting bracket makes installation quick and easy.
CSS-1S/T Competitive Differences
- Must be purchased in pairs for optimal stereo sound distribution.
- Supports both 100V/70V distributed speaker lines and 8 ohm direct mode for flexible installation.
- Includes a 10W multi-tap transformer with 10W, 5W, and 2.5W settings at 70V for distributed systems.
- Designed with professional-grade drivers and crossover network for clear, full-range sound.
- Wide 120ºH x 120ºV nominal coverage pattern for efficient sound distribution.
- Wall-mounting bracket included for secure and easy installation.
CSS-1S/T Description
The
CSS-1S/T loudspeaker is ideal for distributed audio systems where clear, full-range sound is required. Equipped with a 135mm (5.25 inch) low-frequency driver and a 19mm (0.75 inch) polycarbonate dome tweeter, this speaker offers excellent sound quality for both music and speech. It operates in either 100V or 70V distributed systems with a 10W multi-tap transformer and can be switched to 8 ohm direct mode for traditional speaker setups. The CSS-1S/T comes with a durable polypropylene enclosure and an included wall-mounting bracket, making it a versatile choice for various installations. Please note that these speakers are sold and must be purchased in pairs for proper sound performance.
CSS-1S/T Features
- 10W multi-tap transformer for 100V or 70V distributed systems
- 8 ohm direct setting for traditional speaker systems
- 135 mm (5.25 inch) low-frequency driver for rich bass response
- 19 mm (0.75 inch) polycarbonate dome tweeter for clear high frequencies
- Wall-mounting bracket included for convenient installation
- Professional drivers and network ensure optimal sound quality
- Wide 120ºH x 120ºV nominal coverage pattern
CSS-1S/T Specifications
- Frequency Range (-10dB): 85 Hz – 18 kHz
- Frequency Response (±3 dB): 120 Hz – 16 kHz
- Power Capacity: 60 Watts
- Sensitivity: 86 dB SPL (1W, 2.83V at 1m)
- Maximum SPL (1m): 106 dB in 8 Ohm Direct setting, 96 dB at 10W setting
- Nominal Coverage: 120ºH x 120ºV
- Directivity Factor (Q): 6.2
- Directivity Index (DI): 7.9 dB
- Nominal Impedance: 8 ohms (in 8Ω DIRECT mode, selectable)
- Transformer Taps: 10W, 5W, 2.5W at 70V
- Crossover Frequency: 4.3 kHz
- LF Driver: 135 mm (5.25 inch) low-frequency driver
- HF Driver: 19 mm (0.75 inch) polycarbonate dome tweeter
- Input Connectors: Spring-loaded terminals
- Enclosure Material: Polypropylene structural foam
- Color: Black
- Dimensions: 9.0 x 6.3 x 5.6 inches (229 x 159 x 143 mm)
- Net Weight (each): 4.5 lbs (2.0 kg)
- Shipping Weight (pair): 10.5 lbs (4.8 kg)
What's in the Box
- (2) CSS-1S/T Loudspeakers
- (2) Wall-mounting bracket assemblies
JBL CSS-1S/T
(JBL CSS-1S/ T)
