High-Powered 15-Inch Coaxial Loudspeaker with Bluetooth and Remote DSP Control
The
LD Systems ICOA PRO 15 A is a premium 15” active coaxial PA speaker delivering 1500W RMS (3000W peak) of clean, distortion-free power and deep, full-range response. Built for versatility, it's ideal for DJs, musicians, venues, and AV professionals seeking powerful performance, wireless connectivity, and precision DSP—all in a rugged, flexible design.
LD Systems ICOA PRO 15 A Competitive Differences
- Massive 1500W RMS / 3000W peak output with up to 135 dB SPL for high-impact sound
- True coaxial design with common motor ensures phase coherence and point-source clarity
- 15" woofer with 3" voice coil + 3" titanium HF driver for extended full-range response
- Rotatable 90° x 50° BEM-optimized CD horn provides accurate dispersion and midrange focus
- SysCore® DSP with FIR/IIR filtering, multiband limiter, and 4-band parametric EQ
- Bluetooth® 5.1 with stereo streaming (TWS) and app control for easy wireless configuration
- Mobile app for iOS/Android provides remote control of all settings including delay, EQ, and presets
- Tool-free EasyMount® compatibility, 6 M10 rigging points, and dual-tilt pole mount (0°/5°)
- Robust ABS cabinet with steel reinforcement and 50° monitor angle for flexible use
LD Systems ICOA PRO 15 A Description
The
ICOA PRO 15 A stands at the top of LD Systems' ICOA PRO series, offering the precision of coaxial technology and the power of a large-format 15” woofer in a highly portable and durable design. Its coaxial configuration creates a phase-aligned point-source output, enhancing clarity and detail—ideal for both front-of-house and monitor applications.
Designed with professional live sound in mind, this speaker features a 3” titanium HF driver mated to a rotatable horn for customizable horizontal or vertical deployment. At its core, a 1500W RMS Class D amplifier drives up to 135 dB SPL, with smooth frequency response from 50 Hz to 20 kHz.
The internal SysCore® DSP ensures clarity at high volume through advanced FIR/IIR filtering and a multiband limiter. Four factory EQ presets—including a low-latency monitor mode—allow rapid optimization, while the 4-band parametric EQ and delay function offer in-depth control. You can access and fine-tune every setting via the onboard color display or wirelessly using the free ICOA PRO app.
Bluetooth 5.1 with TWS (True Wireless Stereo) makes it easy to stream music and link multiple units without additional cables. Multiple input sources are supported, including two mic/line combo inputs and a dedicated XLR mix output for daisy-chaining.
Thanks to its rugged ABS enclosure with integrated handles, steel reinforcement, and front grille, the ICOA PRO 15 A is built for life on the road. Its built-in 35 mm dual-tilt pole socket, six M10 fly points, and compatibility with EasyMount® hardware mean it adapts easily to mobile and fixed installations alike.
ICOA PRO 15 A Features
- Coaxial 2-way system with 15" woofer + 3" titanium HF driver
- True point-source output for enhanced phase coherence
- 3000W peak / 1500W RMS Class D amplifier
- Max SPL: 135 dB / Frequency response: 50 Hz – 20 kHz
- SysCore® DSP with FIR/IIR filters, EQ, limiter, delay, and presets
- Bluetooth® 5.1 streaming with TrueWireless™ Stereo and app control
- 4-band parametric EQ and 4 application presets including monitor mode
- Dual XLR combo mic/line inputs + XLR mix output
- Rotatable 90° x 50° horn for flexible mounting
- Dual-tilt 35 mm pole mount (0° / 5°), EasyMount® and 6 x M10 rigging points
- Rugged ABS cabinet with steel grille and 4 ergonomic handles
ICOA PRO 15 A Specifications
- Type: Active 2-way coaxial loudspeaker
- Woofer: 15" with 3" voice coil
- HF Driver: 3" titanium diaphragm
- Power Output: 1500W RMS / 3000W Peak
- Max SPL: 135 dB
- Frequency Response: 50 Hz – 20 kHz (-10 dB)
- Crossover: 800 Hz
- Coverage: 90° x 50°
- Inputs: 2 x XLR combo (mic/line), 1 x line input
- Output: 1 x XLR 3-pole male (mix out)
- Bluetooth Version: 5.1 with TWS
- Mounting: 6 x M10, 35 mm dual-tilt pole socket
- Enclosure: ABS with steel grille
- Dimensions (H x W x D): 690.7 x 417 x 414.8 mm (27.2 x 16.4 x 16.3 in)
- Weight: 25.8 kg (56.9 lbs)
From stage monitoring to full-scale live performance, the LD Systems ICOA PRO 15 A delivers all the flexibility, power, and wireless convenience today’s sound professionals demand.
