Advanced 15-Inch Powered Bluetooth® Speaker with Digital Mixer
The
RCF ART 915-AX is a powerful 15" active speaker that integrates a 6-channel digital mixer, Class-D amplification, Bluetooth® audio streaming, and app-based remote control. Designed for pro audio applications, mobile performers, and DJs, it delivers up to 131 dB SPL with advanced DSP, wireless stereo linking, and full control via touch panel or smartphone.
RCF ART 915-AX Competitive Differences
- Integrated 6-channel digital mixer with compressors, EQ, reverb, and ducker
- 2100W peak Class-D amplifier (700W HF / 1400W LF)
- 15” woofer + 1.75” compression driver with 100° x 60° coverage
- Bluetooth® stereo audio input with long-range dual speaker pairing
- FiRPHASE and Bass Motion Control DSP for linear phase and deep low-end
- Color touch panel with rotary encoder + iOS/Android LiveRemote app
- Multiple output modes: MIX OUT, CROSSOVER OUT, STEREO, CH1 LINK
- Rugged PP composite cabinet with M-brace reinforcement and multiple rigging points
RCF ART 915-AX Description
The
RCF ART 915-AX is engineered for professionals who demand power, control, and versatility in a portable PA speaker. Featuring a built-in digital mixer and Bluetooth® streaming, this system is designed to work seamlessly with microphones, instruments, or playback devices — all controlled from the onboard touchscreen or wirelessly via the LiveRemote app.
With a 15" woofer and 1.75" compression driver powered by a 2100W Class-D amplifier, the ART 915-AX delivers clean, high SPL performance with 100° x 60° coverage. RCF’s FiRPHASE and BMC (Bass Motion Control) technologies ensure precise phase alignment and extended low-end response without distortion or loss of fidelity.
From small gigs and mobile DJs to corporate AV setups, this speaker offers flexible I/O, routing options, and built-in DSP tools — including 5-band output EQ, output delay, and crossover presets for RCF subwoofers. Durable and lightweight, it includes rigging points and a pole mount for easy installation and transport.
ART 915-AX Features
- Built-in 6-channel digital mixer
- 15" woofer with 2.5" voice coil
- 1.75" compression driver with 1.0" exit
- 2100W peak Class-D amplifier (700W HF, 1400W LF)
- Max SPL: 131 dB
- Bluetooth® stereo input with dual speaker pairing
- Color touch panel with rotary encoder
- Remote control via LiveRemote app (iOS/Android)
- 3-band EQ on inputs, 5-band parametric EQ on output
- Compressors on MIC/LINE CH1 & CH2 inputs
- Selectable output modes: MIX OUT, CROSSOVER OUT, STEREO, CH1 LINK
- FiRPHASE linear phase processing + Bass Motion Control (BMC)
- Soft limiter, thermal & RMS protections
- 35 mm pole mount, multiple M10 rigging points
ART 915-AX Specifications
- Frequency Response: 45 Hz – 20,000 Hz
- Max SPL: 131 dB
- Coverage: 100° horizontal x 60° vertical
- Woofer: 15” with 2.5” voice coil
- Compression Driver: 1.75” v.c. (1.0” exit)
- Amplifier Power: 2100W peak (700W HF, 1400W LF)
- Cooling: Convection (no fan)
- DSP: 24-bit processing / 32-bit A/D-D/A @ 48kHz
- Dynamic Range: 110 dB
- Mic Inputs: 2 x Combo XLR/Jack (6 kΩ, +48V phantom power)
- Mono Line Inputs: 2 (21 kΩ)
- Stereo Line Input: 1 (13 kΩ, mini-jack)
- Input Gain Range: Mic 0–42 dB, Line 0–22 dB, Stereo 0–10 dB
- Input Noise Level: -114 dBu A-weighted
- Output Connectors: XLR
- Main Output Level: 22 dBu, 150 Ω impedance
- Output Modes: MIX OUT, CROSSOVER OUT, STEREO OUT, CH1 LINK OUT
- EQ:
- Input EQ: 3-band (High/Low shelving, Mid peak)
- Output EQ: 5-band parametric + HPF 24 dB/oct
- Compressor: On CH1 & CH2
- Touchscreen: Color touch panel + encoder
- App Control: LiveRemote (iOS/Android)
- Cabinet Material: Polypropylene composite with M-brace internal reinforcement
- Grille: Steel
- Handles: 1 top, 1 each side
- Rigging: 1 x M10 top, 1 x M10 each side
- Pole Mount: 35 mm insert
- Color: Black
- Dimensions (H x W x D): 28.23 x 16.34 x 16.14 in (717 x 415 x 410 mm)
- Weight: 44.97 lbs (20.4 kg)
- Shipping Dimensions (H x W x D): 29.92 x 18.5 x 18.7 in (760 x 470 x 475 mm)
- Shipping Weight: 54.01 lbs (24.5 kg)
- Safety Compliance: CE certified
