1U Rackmount UPS with Voltage Regulation and Surge Protection
The
Juice Goose KIN1000 is a compact, 1U line-interactive UPS (Uninterruptible Power Supply) designed to protect and regulate power for critical AV, IT, and pro audio systems. With 1000VA/600W capacity, automatic voltage regulation, and integrated surge filtering, it’s ideal for rackmount installations that require reliable backup without sacrificing space.
Juice Goose KIN1000 Competitive Differences
- Line-interactive design with automatic voltage regulation and buck/boost transformer
- Compact 1U rackmount form factor saves valuable rack space
- Up to 11 minutes runtime at half load, 2 minutes at full load
- Surge protection rated at 320 Joules and AC line filtration up to 50dB
- Battery backup power through four NEMA 5-15R outlets, plus one bypass outlet
- Optional network interface via RS-232 or external SNMP card
Juice Goose KIN1000 Description
The
KIN1000 provides 600 watts (1000VA) of reliable backup power with voltage correction and surge filtering, making it ideal for sensitive electronics, servers, and AV equipment. Its line-interactive UPS topology includes a buck-boost transformer that automatically corrects high or low voltages without draining the internal battery, extending battery life and increasing system reliability.
This UPS features four battery-backed NEMA 5-15R outlets and one always-on bypass outlet. It also includes comprehensive status indicators and alarms for low battery, overload, and fault conditions. The unit’s sealed lead acid battery system recharges in approximately 8 hours and includes a replace battery indicator for maintenance tracking.
Designed for convenience and durability, the KIN1000 is housed in a 1U steel chassis and can also be mounted on its side to accommodate unique rack layouts. This UPS is ideal for professional-grade installations where space, performance, and protection matter most.
KIN1000 Features
- Line-interactive UPS with 1000VA / 600W capacity
- Automatic voltage regulation with buck-boost transformer
- 4 battery-backed NEMA 5-15R outlets and 1 bypass outlet
- 320 Joules surge protection with 50dB EMI/RFI filtering
- 1U rackmount steel chassis (can also be side-mounted)
- Optional network management via RS-232 or SNMP card
- Maintenance-free sealed lead acid batteries (3 x 6V 8AH)
- Status LEDs with audible alarms for overload, battery, and low voltage
KIN1000 Specifications
- Power Capacity: 1000VA / 600W
- Input Voltage: 120 VAC
- Input Frequency: 50 or 60 Hz (auto sensing)
- Output Voltage (on battery): Simulated sine wave, ±25% of input
- Voltage Regulation: ±15% buck, ±10% boost
- Transfer Time: 24 milliseconds
- Surge Protection: 320 Joules
- EMI/RFI Filtration: Up to 50dB @ 30MHz
- Battery Type: Sealed lead acid (3 x 6V 8AH)
- Recharge Time: 8 hours to 90% capacity
- Runtime: 11 minutes at half load, 2 minutes at full load
- Receptacles: 4 x NEMA 5-15R (battery), 1 x NEMA 5-15R (bypass)
- Dimensions: 15.0" W x 14.3" D x 1.7" H
- Weight: 25.3 lbs
- Power Cord: 6 ft with NEMA 5-15P plug
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Audible Alarms: Slow beep (battery), fast beep (low battery), continuous (overload)
- Max Altitude: 11,500 ft
