Compact RF Distribution and Power Solution for Wireless Microphone Systems
The
RF Venue DISTRO5 HDR is the latest and highest-performance RF/antenna distribution system engineered for
clean, reliable, and scalable signal management in professional wireless microphone installations. Designed in the USA, it operates across the full 470–698 MHz band and integrates both antenna and DC power distribution in a compact half-rack format.
RF Venue DISTRO5 HDR Competitive Differences
- HDR platform delivers exceptionally clean and low-noise RF performance
- Half-rack size allows cascading up to 9 wireless mic receivers in 1RU space
- Internal 5A power supply eliminates wall warts and supports up to 8 DC devices
- Battery-ready design with 12V DC input for portable/mobile setups
- Includes rack ears and joining hardware for flexible integration
RF Venue DISTRO5 HDR Description
Building on the success of the DISTRO4, the
DISTRO5 HDR takes signal clarity and reliability to a new level. It’s part of RF Venue’s
High Dynamic Range (HDR) product family, purpose-built for robust performance in high-demand RF environments. This unit allows
one diversity antenna pair to feed
five wireless receivers and provides cascade capabilities for even larger setups—up to nine channels in just 1RU using optional accessories.
Beyond antenna distribution, the
DISTRO5 HDR is also a centralized power hub for your rack gear. With its optional
Octopus cable, the internal 12V 5A power supply can directly feed up to 8 wireless receivers, eliminating bulky wall power adapters and clutter.
Perfect for
installed AV systems, mobile broadcast carts, or field production rigs, the DISTRO5 HDR gives professionals a compact, future-proof backbone for audio signal reliability.
RF Venue DISTRO5 HDR Features
- 5 pairs of diversity RF outputs
- 1 pair of diversity antenna inputs
- Cascade outputs for expanding setups
- Internal IEC power supply (no wall wart)
- 12V DC output up to 5A for powering rack gear
- Optional 12V DC input for mobile battery use
- Half-rack width, includes rack ears and joining plate
DISTRO5 HDR Specifications
- Operating Band: 470–698 MHz
- Diversity RF Outputs: 5 pairs
- Diversity Antenna Inputs: 1 pair
- Power Supply: Internal (IEC input)
- DC Output: 12V, 5A (Octopus cable optional)
- DC Input: 12V for battery-powered operation
- Form Factor: Half-rack with included connecting plate and rack ears
What’s In The Box
- DISTRO5 HDR unit
- IEC power cord
- Short and long rack ears
- Half-rack joining plate with mounting hardware
Optional coaxial and DC cable kits sold separately or included in RF Venue bundles.
RF VENUE DISTRO5HDR
(RF Venue DISTRO5-HDR)
