Powerful 15" Active Loudspeaker with Bluetooth and DSP
The
Proel Diva 15A is a high-performance 2-way active loudspeaker system designed for professional audio applications. Featuring a powerful 1000W Class D amplifier, a 15” woofer with a 2.5” voice coil, and a high-definition 1” compression driver, this speaker delivers exceptional sound clarity and deep bass response. With built-in DSP processing, Bluetooth streaming, and a 3-channel mixer, the Diva 15A is perfect for DJs, live performances, and portable PA setups.
Proel Diva 15A Competitive Differences
- **High Power Output:** 1000W peak Class D amplifier with SMPS for high efficiency and low distortion.
- **Advanced DSP Processing:** 24-bit high-definition DSP with FIR filters for precise sound tuning.
- **5 DSP Presets:** MUSIC, LIVE, DJ, MONITOR, SPEECH modes for versatile sound optimization.
- **Integrated 3-Channel Mixer:** Features MIC/GUITAR/LINE inputs, stereo Bluetooth, and EQ controls.
- **Bluetooth Streaming with TWS:** Connects wirelessly for mono or stereo streaming with another Diva 15A.
- **Durable & Lightweight Design:** Polypropylene cabinet with ergonomic handles for easy portability.
- **Flexible Mounting Options:** Slanted design for floor monitoring and M10 flying points for suspension.
- **Wide Sound Coverage:** 90° x 60° horn for even sound dispersion.
- **High SPL Output:** Delivers up to 129 dB for powerful sound reinforcement.
Proel Diva 15A Description
The
Proel Diva 15A is engineered for professional sound reinforcement, featuring a high-efficiency Class D amplifier with SMPS, ensuring maximum output power while maintaining low power consumption. Its 15” long-excursion woofer and 1” compression driver deliver deep bass, clear mids, and crisp highs with minimal distortion.
A built-in 24-bit DSP processor with FIR filters provides high-definition sound tuning, offering five EQ presets to adapt to different environments and applications. Whether you need enhanced clarity for speech, punchy bass for DJs, or balanced sound for live performances, the Diva 15A has you covered.
The integrated 3-channel mixer includes MIC/LINE inputs, EQ controls, and Bluetooth connectivity for wireless audio streaming. With STEREO LINK (TWS) functionality, you can pair two Diva 15A speakers for a seamless stereo sound experience.
Designed for durability and ease of transport, the lightweight polypropylene cabinet includes ergonomic handles, a slanted shape for use as a stage monitor, and four M10 flying points for installation. Its wide coverage horn (90° x 60°) ensures consistent sound dispersion, making it ideal for small to medium-sized venues, DJs, and portable PA applications.
Proel Diva 15A Features
- 2-way active processed loudspeaker system
- 1” high-definition compression driver with 1.35” VC and titanium diaphragm
- 15” long-excursion woofer with 2.5” voice coil
- 1000W peak Class D power amplifier with SMPS
- Built-in 3-channel mixer with MIC/LINE inputs and HIGH & LOW EQ controls
- 24-bit DSP with FIR filters for superior sound processing
- 5 DSP presets: MUSIC, LIVE, DJ, MONITOR, SPEECH
- Bluetooth audio streaming with STEREO LINK (TWS) for wireless stereo pairing
- Color LCD display for DSP editing and control
- Maximum SPL: 129 dB
- Frequency response: 45 Hz - 20 kHz
- Lightweight and durable polypropylene cabinet
- 90° x 60° wide-coverage horn
- Slanted shape for stage monitor use
- Four M10 flying points for installation
- Two ergonomic handles for easy transport
- Standard pole mount for speaker stands
Proel Diva 15A Specifications
- System Type: 2-way vented enclosure
- High-Frequency Driver: 1” compression driver with 1.35” VC and titanium diaphragm
- Low-Frequency Driver: 15” woofer with 2.5” voice coil
- Angular Coverage: 90° H x 60° V
- Total Peak Power: 1000W
- HF Amplifier Power: 100W Class AB
- LF Amplifier Power: 400W Class D
- System Processing: DSP with 24-bit converters
- Frequency Response: 45 Hz - 20 kHz
- Max SPL: 129 dB
- Inputs: 2 x MIC/LINE (COMBO), 1 x STEREO LINE (MINIJACK), 2 x USB WIRELESS
- Outputs: 1 x MIX OUT / CH1 LINK (M-XLR)
- Controls: Channel level, input selector, HIGH & LOW EQ, rotary push encoder, color LCD
- Bluetooth: Version 5.0, audio streaming, STEREO LINK (TWS)
- Power Supply: 100-120V~ or 220-240V~ at 50/60 Hz with auto-switch
- Rated Power Consumption: 300W
- Floor Monitor Angle: 45°
- Flying System: 4 x M10 mounting points
- Cabinet Material: Polypropylene
- Handles: 1 x top, 1 x side
- Mounting Pole: 1 x bottom
- Dimensions (W x H x D): 16.6” x 27.4” x 15” (421 x 696 x 382 mm)
- Weight: 41.8 lbs (19.0 kg)
